Décortech Multigroove Acoustic Perforation
Description

Décortech Multigroove is available as either an acoustic panel with perforations both sides (15mm or 16mm thick substrate) or as a decorative panel with Face Side perforations only (12mm thick substrate). The face appearance of the acoustic and decorative Multigroove is exactly the same.

There are a number of standard options available with square edge or ship lapped edge details. The Multigroove perforation can also be customised so talk to Décortech about other options.  Multigroove is available as standard in 2400 x 1200mm sheet sizes however panels sizes are fully customisable and can be tailored to fit any space.

Substrates available are painted or real timber veneered MDF or Firesafe MDF (Group 1-S), or Plywood.

Décortech panels are pre-finished, saving time and cost onsite and reducing potential issues such as spills, overspray or damage.

Décortech MultiGroove panels can be easily installed by screwing, panel pinning or stapling to wooden battens.  For stapling, a customised pneumatic staple gun is available on loan from Décortech subject to availability and terms and conditions.

Key Features
  • Standard options include 3/16 (3mm grooves at 16mm centres), 3/32 (3mm grooves at 32mm centres), 3/48, 3/100, 6/32, 6/48, 6/100 with a shiplapped edge detail.
  • Substrates available are painted or real timber veneer MDF or Firesafe MDF (Group 1-S).
  • Décortech Multigroove Planks come in a standard 2400 x 288mm size and can be easily installed using the Décortech Clip and Rail System.
  • All panels come with Decoustic 85 felt bonded to the back as standard.
  • Acoustic blanket can also be provided if required.
Statement of Building Code Compliance
  • Multigroove Acoustic Perforation with Firesafe MDF substrate meets NZ Building Code: Clause C - Interior Fire Rating Group 1S
C Protection from Fire compliant
Protection from Fire
Interior Fire Rating 1S
1S
Documents
Data Sheet
