DORMA ES 200 Automatic Sliding Door Operator
Description

The DORMA ES 200 encompasses a stylish and modern cover design, a motor that ensures a virtually silent operation, a microprocessor that automatically controls the opening and closing speeds of the door, an energy saving power unit and new programming functions allowing for quick and simple installation, set-up and maintenance.

Key Features
  • Total door weights, Single Slider 170 kg per pane, Bi-parting 140kg per pane
  • Available operator heights: 150 mm only
  • Smooth and quiet operation
  • Suitable for small to medium door applications
  • Modular, flexible system
  • With DORMA PowerDrive: Dynamic driving phase control for particularly powerful operation
  • Emergency power backup in form of rechargeable battery pack
  • Industrially prefabricated and tested MiniDriveUnit
  • Reliable investment due to compliance with all relevant NZ standards
  • Modular upgradeable with additional function modules
  • Easy commissioning via the integrated display
Scope of Use

The equipment is designed for mid range commercial automatic sliding doors with maximum door weights of 170kg per single door and 140kg for bi-parting doors.

Suitable for framed doors or frameless glass doors upto 15mm thick.

The equipment may be fully integrated into a Building Management System with all appropriate outputs

  • Fire
  • Failsafe
  • Mains Power
Limitations on Use

Maximum door weights of 170kg per single door and 140kg for bi-parting doors.

Statement of Building Code Compliance

To ensure a high level of safety, the product is tested and complies to N.C.C and is certified by an independent NATA AS5007 accredited lab.

In-Service History

Infrax West - Torhout (BEL)

The new administration centre of the Belgian energy utility WVEM in Torhout is an architectural highlight that serves as a model for a new generation of energy-efficient office buildings.

Thanks to the interplay of different systems and technologies, energy consumption is reduced by 35%, and CO2 emissions by 36%, compared to conventional office buildings of a similar genre.

The door systems and glass fittings and accessories from DORMA further contribute to this positive energy balance. The ES 200 automatic sliding door operators are not only easy to use but, thanks to their high functional efficiency and longevity, also contribute significantly to the sustainability credentials of the build.

Literature
Other Literature
Brochure
CAD/PDF Details
ES 200 NZ Framed
ES 200 NZ Frameless 12mm
ES 200 NZ Frameless 15mm
