PanelSafe Range Seismount
Description

The PanelSafe Seismount is a strong solution for high volume architectural installation where added security and control of the panel is required. The Seismount allows the panel to be suspended below the ceiling for convenient servicing behind the panel or controlled removal of the panel.

Available in either galvanised steel (SR225S) or stainless steel (SR225SS) with a drop length of 225mm. 144kg break load for the PS-SR225S in both wall and ceiling applications.

Key Features
  • Low cost solution for high volume applications
  • No special tools required for installation
  • Install directly onto substrate face with screws
  • Controlled removal of large panels
  • Seismic security for overhead panels — prevents panels from falling
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

Solution for high volume architectural installation where added security and control of the panel is required

  • Seismic security for overhead panels
  • Allows the panel to be suspended below the ceiling for convenient servicing
  • Drop length 225mm
  • 144kg break load for the PS-SR225S in both wall and ceiling applications
  • Install directly onto substrate face with screws

Applications:

  • Ceiling panels
  • Wall panels
  • Large panels
  • Inspection and service panels

For use with Fastmount system clips:

  • PC Standard Range
  • LP Low Profile Range
  • VL Very Low Profile Range
  • MC Metal Range
  • SL Stratlock Range
Limitations on Use
  • See Installation Guide for full information
  • Refer to Clip Selection Guide for suggested panel + substrate applications
  • Fastmount Panel Mounting Systems are not recommended for exterior panels
In-Service History

Fastmount Panel Mounting Systems were developed for the high performance demands of the superyacht industry, and have been used in thousands of commercial and residential building projects in New Zealand and around the world since 2004.

Other Performance Attributes
  • Pull-out loads independently tested by SGS New Zealand
  • Fastmount has a two year limited warranty on all products
Documents
Installation Guide: Seismount

10/19

Product Sheet: PS-SR225S

10/19

Product Sheet: PS-SR225SS

10/19

Test Certificate: PC-SR225SS

INZ66469-02 12/16/19

Maintenance Document
Warranty Information
Product Catalogue Technical Guide

09/20

Fastmount Clip Selection Guides

Architectural & Marine

Fastmount design and manufacture hidden panel mounting systems for interior panels, allowing architects and installers to re-think the panelling process.
