• Wall and ceiling battens
• Integrates with suspended ceiling brackets — TCR / mounting track is uniquely designed so it can be mounted to suspension ceiling hangers.
• Screwed to existing walls & ceilings — TCR / mounting track can be directly screw-fixed to most substrates on walls & ceilings.
• Modular clip & spacer — clip in system is simple and smart for fast and easy installation. Spacing is preset, but can also be adjusted on site.
• Battens can be removed at any point in time.
• LED light integration: Battens are designed to accept an integrated LED strip and single driver per unit. So every batten can become an in-line light strip without needing to mount lights in between battens or cut out penetrations to install lights.

Fire Compliance details

1. Consult with the architect or interior designer to determine if the ceiling or walling system is situated on a designated fire egress route.

2. Verify if the building is equipped with fire sprinkler systems, either installed or planned.

3. Our standard offer utilizes non-combustible Aluminium battens 6000 series (melting point: 660°C) in combination with nylon PA66

(plastic) clips.

4. For areas involving fire egress, utilize metal clips and aluminium battens as they offer higher melting points (melting at 1427°C).

5. Employ a Mild steel rondo ceiling grid system, with a melting point of 1427°C, for the remaining assembly.

6. Cedar & hemlock have a Group Number of 3 according to NZBCC3.4(a), ISO9705 & AS3837 standards.

7. Ensure the client has obtained approval from their fire engineers or certifier for the design proposal.

8. Adhere to BCA Specifications NZBC - C3.4(a) & NCC C1.10 requirements for walls and ceiling linings:

- (a) Ensure the wall or ceiling lining system complies with the specified group number in Table below and, for buildings

without a sprinkler system complying with Specification E1.5, meets one of the following: (i) A smoke growth rate index not exceeding 100; or (ii) An average specific extinction area less than 250 m2/kg.

- (b) Determine the group number of the wall or ceiling lining and the smoke growth rate index or average specific extinction area in accordance with NZBCC1-C6 & AS 5637.1. Confirm that a fire engineer has reviewed the ISO5660 flow chart.

Sound absorption estimates

Nacci PET backing for interior applications. PET backing is provided, delivering excellent acoustic performance to enhance the overall environment. It is supplied in set widths to fit perfectly between the mounting tracks.

Thermally bonded polyester fibre insulation is specifically crafted to deliver exceptional sound absorption across various frequencies

- Offered in diverse thicknesses and densities to suit different needs.

- Engineered with carefully balanced fibre blends to maximize acoustic and thermal performance in a wide array of industrial, community, residential, and commercial settings.

- Non-irritating, eliminating the need for protective clothing or masks during installation.

- Standardly available Black, other colours available upon request.

Materials & Specifications

Grade: Natural Select grade timber consists of a minimum of 2/3 Select grade and a maximum of 1/3 Standard grade, Minimal surface checking is permitted, and grading is applied to the top face only.

Timber Batten Length: Timber is supplied in random lengths ranging from 1.8m to 6.0m unless otherwise specified. The average length is approximately +/- 2.7m.

Colour Selection: Colour variation is natural and not part of the grading process. Colours can range significantly from rich browns to greys due to the natural characteristics of timber.

Species Selection: Timber is selected based on known trade names such as Western red, cedar Yellow, cedar Hemlock, Sapele Mahogany, Douglas Fir, Rosewood. Other species are available upon request.

Durability Rating NZBC (B2AS1) & (AS 5604): Please see Building standards for durability ratings of standard and nonstandard timbers.

Profile Accuracy: Manufactured profiles have a tolerance of +/- 1mm in dimension and profile. Individual boards may swell or contract due to variations in timber moisture and characteristics when exposed to the elements.

Maintenance: Regular maintenance is necessary for natural timber to prevent cracking and twisting. The frequency of oil application depends on factors such as sun exposure, rainfall, UV blockage, and western sun exposure. Cutek oils are recommended for maintenance to retain the timber's natural beauty and colour.

Interior Surface Finishes: UV coatings are suitable for interior applications and areas out of direct sunlight and rain. Satin finishes enhance the character and colour of Western Red Cedar, while washes provide a maintenance-free option for internal and out-of-weather applications. Satin washes offer striking colours and consistency, while matte washes provide trendy colours with a matte finish on Hemlock timber.

Sustainable Materials:

• FSC® and PEFC™ certified timber ensures sustainable forestry practices.
• Aluminium components manufactured locally using raw material from Tiwai Point Smelter
