New Premium Synthetic FR White Faced Foil: DriStud W11

DriStud W11 is a fire retardant, vapour barrier, light diffuser and is water resistant. W11 is used as an interior lining for warehousing facilities and commercial and industrial buildings where an extra clean white finish is required.

Extra Titanium Dioxide is added to the non-woven polypropylene to give it a premium white finish that helps disperse ambient light, creating a brighter space. The blue layer on the upper side is a semi-reflective layer to slightly lower glare. It is also a stiff product with superior tear resistance, and with 150mm lap lines, it is easy and quick to install.

This is a five layer synthetic foil that has been heat laminated without any adhesives, eliminating possibilities of delamination. This means W11 is an inert product while remaining durable and self-supporting. The aforementioned white faced foil is also classified as a suspended flexible fabric and membrane structure with a FR index of 1 when tested to AS 1530 Part 2.

Technical properties

PropertyStandardValue
Total weight   190 5g/m²
Roll Sizes (m²)   1350mm x 55.6m (75m²)
Flammability index AS1530.2-1993 1
Fire retardant   Yes
Resistance to dry delamination AS/NZS 4200.1:1994 Pass
Resistance to wet delamination AS/NZS 4200.2:1994 Pass
Reflectivity AS/NZS 4201.5 >90%
Resistance to water penetration AS/NZS 4201.4:1994 High (Water Barrier)
Vapour barrier ASTM E96 Yes
Durability (years) B2.3.1 (b) 15
Roof pitch   >3 degrees
View more information on DriStud, including contact details.
