• Designed for use in tested passive fire protection solutions.
• Used in seismic gaps vertical and horizontal.
• Both edges of the Firefly material require mechanical fixing/clamping to the face/top of the floor/wall.
• FRR -/120/30

Width limited to that being capable of construction when other factors regarding application are considered using one 1300mm width of material. Refer to TBA Firefly installation documents for details on fixing and material allowances for movement.

The product will, if employed in accordance with the supplier's installation and maintenance requirements, assist with meeting the following provisions of the building code:

• Clause C3 Fire affecting areas beyond the fire source: Performance C3.9
• Clause C4 Movement to place of safety: Performance C4.3

Tested in accordance with AS1530.1 non combustibility.

AS1530.3 simultaneous determination of ignitability, flame propagation, heat release and smoke release.

Tested and assessed in accordance with AS1530.4 2014 and AS4072.1 2005.
