The Silca and TreadTech systems are fully compatible with Viking Buzon Pedestals, supporting both paver and timber decking applications.

Designed for use over waterproofing membranes, they provide an elevated, free-draining floating deck solution suitable for residential and commercial environments.

Show more

• Clause B1 Structure: Performance B1.3.1
• Clause B2/AS1 Durability
• Clause E2/AS1 External Moisture

Show more

Compatible with both paver and timber decks, the deck surface sits above (in most cases) a waterproofing membrane. The slope correction mechanism on top of the pedestal allows the deck surface to lay perfectly flat (0% slope) above the waterproofing membrane which slopes away from the building for drainage purposes, and Buzon pedestals range in height from 17mm to 620mm.

Viking Buzon pedestals can support any type of timber decking or ceramic, stone, concrete paving or flag material, as well as fibreglass or metal grid panels. They are suitable for the smallest residential balcony projects through to large bridge walkways, industrial platforms or large civil projects for public spaces such as those requiring water and power reticulation below the ground which can be easily accessed.

Viking Buzon pedestals are suitable for any kind of stable substrate, including applications directly over insulation panels.

Show more

• Clause B1 Structure: Performance B1.3.1
• Clause B2/AS1 Durability
• Clause E2/AS1 External Moisture

Show more

Viking Dec-K-ing PVC Waterproofing Membrane has been appraised for use as a waterproofing membrane for buildings within the following scope:

• on pedestrian decks and balconies; and,
• scope limitations of NZBC Acceptable Solution E2/AS1, paragraph 1.1; and,
• with timber supporting structures designed and constructed in accordance with the NZBC; and,
• with substrates of plywood sheet and compressed fibre cement sheet.

Viking Dec-K-ing PVC Waterproofing Membrane has also been appraised for use as a waterproofing membrane for external reinforced concrete pedestrian decks and balconies for buildings within the following scope:

• up to 3 storeys with a maximum height from ground to eaves of 10m and with a floor plan area limited only by seismic and structural control joints; and,
• with the reinforced concrete structure designed and constructed in accordance with the NZBC.

This appraisal is limited to pedestrian decks and balconies within the following scope:

• constructed to suitable falls (refer paragraphs 12.1 - 12.9 of the Viking Dec-K-ing BRANZ Appraisal); and,
• with no steps within the deck level, no integral roof gardens and no down pipe discharging directly onto the deck.

The design and construction of the substrate and movement and control joints are specific to each building, and are therefore the responsibility of the building designer and building contractor, and are outside the scope of this appraisal.

Show more

• Clause B1 STRUCTURE: Performance B1.3.1 and B1.3.2. Viking Dec-K-ing PVC Waterproofing Membrane meets this requirement.
• Clause B2 DURABILITY: Performance B2.3.1 (b), 15 years. Viking Dec-K-ing PVC Waterproofing Membrane meets this requirement. See paragraph 9.1 of the Viking Dec-K-ing BRANZ Appraisal.
• Clause D1 ACCESS ROUTES: Performance D1.3.3 (d). Viking Dec-K-ing PVC Waterproofing Membrane meets this requirement. See paragraph 7.6 of the Viking Dec-K-ing BRANZ Appraisal.
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.1 and E2.3.2. Decks and balconies incorporating Viking Dec-K-ing PVC Waterproofing Membrane meet these requirements. See paragraphs 12.1 - 12.8 of the Viking Dec-K-ing BRANZ Appraisal.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Viking Dec-K-ing PVC Waterproofing Membrane meets this requirement and will not present a health hazard to people.

Show more

BRANZ Appraised
