AMF Thermatex Thermofon Black Ceiling Tile
Description

AMF Thermatex Thermofon Black provides high sound absorption. The light weight and perforations of the core board has created a Class A sound absorber. With a strong black surface the appearance of AMF Thermatex Thermofon is smooth and elegant. New generation bio-soluble mineral wool, clay and starch contributes to the excellent acoustic performance.

The AMF Acoustic Range carries the Declare label.

Key Features
  • Exposed system, demountable ceiling
  • Dimensions 600 x 1200mm (further sizes available on request)
  • Thickness / weight: 15 mm (c. 2,6 kg/m²)
  • Edges details SK
  • Colour: Black
Red List Material Free
Red List Material Free
Scope of Use
  • Thermatex Thermofon displays excellent sound absorption values and is therefore suitable for damping rooms
  • Great for office buildings, schools, public buildings, workshops, auditoriums
  • Exposed system, demountable ceiling
Other Performance Attributes
  • Fire rating — Building material class A2-s1, d0 as per EN 13501-1 (equivalent to Group 1-S)
  • Sound absorption EN ISO 354 αw = 0.80(H) as per EN ISO 11654
  • NRC = 0.85 as per ASTM C 423
  • Sound attenuation Dn,f,w = 28 dB as per EN 10848 (15 mm thickness, according to test certificate)
  • Light reflectance Up to black 3,8%
  • Thermal conductivity λ = 0,038 W/mK as per EN 12667
  • Humidity Up to 95% RH11/
Interior Fire Rating 1S
1S
Documents
Data Sheet
