• Suitable for light maintenance foot traffic
• Roof Solutions — suitable for installing over plywood, concrete or Nuratherm insulated roof substrates
• Deck Solutions — waterproofing for decks, gutters, terraces and canopies

Show more

In the opinion of BRANZ , the Nuraply Roof and Deck Membranes, if designed, and used, installed and maintained in accordance with with the statements and conditions of Appraisal No.547 (2014), will meet the following provisions of the NZBC:

• Clause B2 Durability: Performance B2.3.1(b), 15 years. Nuraply Roof and Deck Membranes meet these requirements.
• Clause E2 External Moisture: Performance E2.3.1 and 2.3.2. Nuraply Roof and Deck Membranes meet these requirements.
• Clause F2 Hazardous Building Materials: Performance F2.3.1. Nuraply Roof and Deck Membranes meet these requirements and will not present a hazard to people.

Nuraply Roof and Deck Membranes have been appraised as an Alternative Solution in terms of New Zealand Building Code compliance.

Show more

BRANZ Appraised

CodeMark

Nuraply TPO Roof and Deck Membrane Systems are for use as roof and deck waterproofing membranes on buildings within the following scope:

• the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1; or,
• the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1 with respect to building height and maximum floor plan area when subject to specific structural design; and,
• with building structures designed and constructed to meet the requirements of the NZBC; and,
• with substrates of plywood or suspended concrete slabs; and,
• with minimum falls for roofs of 1:30 and decks of 1:40
• with decks that have a maximum area of 40 m2; and,
• situated in NZS 3604 Wind Zones, up to, and including Extra High

Nuraply TPO Roof and Deck Membrane Systems are also for use as roof and deck waterproofing membranes on buildings within the following scope:

• subject to specific structural and weathertightness design; and,
• with substrates of plywood or suspended concrete slab; and,
• situated in specific design wind pressures up to a maximum design differential ultimate limit state (ULS) of 3 kPa; and,
• with the weather-tightness design of all junctions for each specific structure being the responsibility of the building designer.

Roofs and decks waterproofed with Nuraply TPO Roof and Deck Membrane Systems must be designed and constructed in accordance with the following limitations:

• nominally flat roofs and decks and pitched roofs constructed to drain water to gutters and drainage outlets complying with the NZBC; and,
• with no integral roof gardens; and,
• no steps in level within the deck area, no integral roof gardens and no downpipes direct discharge to decks; and,
• with deck membranes continually protected from physical damage by a pedestrian protection system. The design and construction of the substrate and movement and control joints is specific to each building, and therefore is the responsibility of the building designer and building contractor.

Show more

In the opinion of BRANZ, Nuraply TPO Roof and Deck Membranes, if designed, used, installed and maintained in accordance with the statements and conditions of this Appraisal, will meet the following provisions of the NZBC:

• Clause B2 Durability: Performance B2.3.1 (b) 15 years, Nuraply TPO Roof and Deck Membranes meet this requirement.
• Clause E2 External Moisture: Performance E2.3.1, E2.3.2 and E2.3.6. Roofs incorparating Nuraply TPO Roof and Deck Membranes meet these requirements.
• Clause F2 Hazardous Building Materials: Performance F2.3.1. Nuraply TPO Roof and Deck Membranes meet this requirement and will not present a health hazard to people.

Show more

BRANZ Appraised
