Viking Phoenix Super APAO
Description

Viking's 'Platinum' torch-on solution can be installed anywhere in the world. It is an APAO membrane that incorporates the best of APP and SBS membrane features.

Viking Phoenix Super APAO possesses all of the durability properties inherent in the Gemini APP membrane, with the elastomeric advantages in the Lybra SBS, resulting in a premium system. A key benefit is its unequalled cold flexibility down to (-35°C), coupled with high temperature resistance of +140°C. This means it can be used in any climate and will last longer than other systems.

Viking Phoenix Super APAO consists of a 4mm thick base sheet and a 4mm ceramic chip cap sheet which is then installed on top. It is installed in the same way as the other systems.

Viking Torch-on Phoenix Super APAO is CodeMark and BBA (British Board of Agreement) certified. BBA is one of the world’s highest accreditations for a construction product.

Key Features
  • Formulated to suit a wide range of climatic conditions
  • Cold Flexibility Range: -35°C up to +140°C
  • Total Thickness: 8mm, roll width: 1m, roll length: 10m
  • Installed only by Viking Licensed Applicators
  • UV resistant
  • Thermal ageing resistance
  • Dimensional stability
  • Tensile resistance
  • Overlay option
  • 25-year product warranty
  • BRANZ Appraised (Appraisal No. 948)
  • CodeMark Certified (Certificate No. 30092)
NZ-Owned Business
NZ-Owned Business
Scope of Use

Viking Phoenix Super APAO is suited to tricky / confined roofs where it can be 'bled' in to vulnerable areas such as tight corners and awkward areas susceptible to leaks like roof penetrations, internal corners and gutter junctions.

It is suitable for low-slope roofs (flat or curved), gutters and parapets, waterproofing beneath a floating deck, inland and coastal conditions, commercial and residential buildings.

Viking Phoenix Super APAO Waterproofing Membrane has been assessed as a roof waterproofing membrane on buildings within the following scope:

  • The scope limitations of NZS 3604:2011 and NZBC Acceptable Solution E2/AS1, Paragraph 1.1; or,
  • The scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1 with regards to building height and floor plan area when subject to specific structural design; and,
  • Situated in NZS 3604:2011 Wind Zones, up to and including Extra High; and,
  • With substrates of plywood or suspended concrete slab; and,
  • With a minimum fall for roofs of 1:30 (2 degrees).
  • Viking Phoenix Super APAO Waterproofing Membrane has also been assessed for use as roof waterproofing membranes on buildings within the following scope:

Subject to specific structural and weathertightness design situated in wind pressures up to a maximum design differential ultimate limit state (ULS) of 6 kPa: and,
With substrates of plywood or suspended concrete slab.

Limitations on Use
  • The system must be installed by a Viking Roofspec Trained and Approved Installer
Statement of Building Code Compliance
  • Clause B1 STRUCTURE: Performance B1.3.1 and B1.3.4 (b) (c) (d) (e) for the relevant physical conditions of B1.3.3 (p). Viking Phoenix Super APAO Waterproofing Membrane meets this requirement.
  • Clause B2 DURABILITY: Performance B2.3.1 (b), 15 years. Viking Phoenix Super APAO Waterproofing Membrane meets this requirement.
  • Clause E2 EXTERNAL MOISTURE: Performance E2.3.1, E2.3.2 and E2.3.7 (b) and (c)Viking Phoenix Super APAO Waterproofing Membrane meets these requirements.
  • Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Viking Phoenix Super APAO Waterproofing Membrane meets this requirement and will not present a health hazard to people.
Other Performance Attributes
  • BRANZ Appraised (no. 567, 2016);
  • Viking Phoenix Super APAO is backed by a 25 year product warranty and for specific projects, is eligible for Viking's Full System Warranty, which covers the product and installation in one document.
  • The bitumen used in Viking Phoenix Super APAO is a bi-product of the oil refining process, providing a constructive use of this waste product;
  • A Viking Phoenix Super APAO roof can be overlaid at the end of its useful life, avoiding the dumping of the old roof and the filling of landfills with inorganic waste.
B1 Structure compliant
Structure
B2 Durability compliant
Durability
E2 External Moisture compliant
External Moisture
F2 Hazardous Building Materials compliant
Hazardous Building Materials
BRANZ Appraised
BRANZ Appraised
Documents
Product Technical Statement
Material Safety Data Sheet
BRANZ Appraisal

no. 948 (amended 2019)

Maintenance Instructions
Warranty
Code of Practice
Find an Approved Installer
Substrate Checklist - Concrete
Substrate Checklist - Plywood
Substrate Checklist - Strandsarking
Brochure: Viking TorchOn
Additional Information
CAD/PDF Details
Viking Torch-On Details Full Set
