AMF Thermatex Alpha HD 19, 30 + 35
Description

AMF Thermatex Alpha HD is the extremely absorbing plank ceiling from the AMF Acoustic Range.

The range is suited for New Zealand schools, meeting DQLS requirements. The elegant white acoustic fleece provides a high quality surface.

The AMF Acoustic Range carries the Declare label.

Key Features
  • System: Two way exposed grid system
  • Dimensions: 1200 x 600mm (other sizes available on request)
  • Thickness / Weight: 19mm (c. 5.2 kg/m²), 30mm (c. 8.2 kg/m²), 35mm (c. 9.5 kg/m²)
  • Colour: White similar to RAL 9010
  • Edge details: SK (other profiles available on request)
Red List Material Free
Red List Material Free
Statement of Building Code Compliance
  • Suited for New Zealand schools, meeting DQLS requirements
Other Performance Attributes
  • Fire resistance: Group 1-S (as per ISO 5660 Parts 1 and 2)
  • Light reflectance: up to 88%
  • Thermal conductivity: λ = 0.052 - 0.057 W/mK as per DIN 52612
  • Humidity: up to 95 % RH
  • Clean room: Class 4 as per ISO 14644-1
Interior Fire Rating 1S
1S
Documents
Data Sheet

05.02.2021
