Triton 50 HD by Asona

Triton 50 HD

Description

Triton 50HD™ is a made in New Zealand high sound absorbing ceiling panel that is designed to control unwanted noise reverberation and with a HD core for attenuation of plenum noise and room to room noise. Panels are available in standard and large sizes and in a wide range of decorative acoustic finishes, colours, wood prints and perforated laminate designs. Also available with a Sonatex Hygiene laminate facing. High NRC and CAC 35 for combined acoustic performance.

Key Features

NRC 0.95, 50 mm thick panel provides superior sound absorption at low to high frequencies in either direct fix over plasterboard or as a suspended ceiling
CAC 35 as standard
Large panels up to 1200 x 1200mm or 600 x 2400mm provide for a cleaner look with fewer panel joins compared to standard 600 x 1200mm size
Fire Group 1-S
Broad range of Sonatex™ and Sonaris™ decorative acoustic laminate finishes for design flexibility
Panels available with temporary protective foil covering to keep the panels clean during installation — ideal for service panels
Custom size border panels help give perimeters a cleaner look
Made in NZ, short lead times including replacement parts
Packaging take back and reuse scheme available (NZ only)
Product stewardship Renew and Reuse program
Durable and dimensionally stable in high humidity
GreenTag certified Level A, low VOC, core contains 80% recycled post consumer waste glass.
Light weight for seismic areas, easy to work and trim.
Optional Sonatex Hygiene laminate facing.

Ranges

Thermal Triton Sonaris Hygienic Decorative

NZ Made

NZ-Owned Business

Pre-Consumer Recycled Content

Scope of Use

Triton 50HD™ is an ideal retrofit acoustic panel for classrooms, offices, community halls when applied directly over plasterboard in large sheets or as a suspended grid and panel ceiling.

Limitations on Use

For interior use only, and not in direct contact with water.
Shall not commence until the building is water tight and dry
Light fittings shall be independently supported
Back Loading — Max. 1.5 kg/m², point loads shall be independently supported
Use hold down clips in areas of wind uplift
May be used for negative air return plenums however careful design and installation is required. Consult your HVAC or Mechanical Engineer prior to install.
Use Rondo Donn DXW T38 wide faced grid for large module panels (600mm x 2400/1200/1200mm)
Max 99% R/H at 45°C

Statement of Building Code Compliance

NZ Building Act

This product is not subject to a warning or ban under Section 26.

NZ Building Code Compliance:

B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
C3 Fire – Clause C/AS2 4.12.1: Asona Triton 50HD has a Fire Material Group Number 1-S by NZBC Building Product Specification Parts 8.5.4 or 8.5.5, tested in accordance with ISO 9705 or ISO 5660. (NCC BCA C1.10 clause 4, spec A2.4 clause 4. Group 1)

In-Service History

Multiple projects

Other Performance Attributes

Global Green Tag Certified, Class A, core contains 80% recycled local glass waste, low VOC <0.005 Mg/M²/hr per ASTM D5116.
Packaging return, panel recycle and renew programs
Light Reflectance — 85% per BS8493:2008, White
Thermal Resistance — R 1.47 m²°C/W
NRC 0.95
CAC 35 as standard
Packaging take back and reuse scheme available
Optional Sonatex Hygiene laminate facing.
