Triton 50 by Asona

Triton 50

Asona

All products

Product Enquiries

Description

Triton 50™ is a made in NZ high sound absorbing ceiling panel that is designed to control unwanted noise reverberation. Panels are available in sizes up to 1200 x 2400 mm and in a wide range of decorative acoustic finishes, colours, wood prints and perforated laminate designs. High NRC and CAC 30 for combined acoustic performance.

Manufactured from 48 kg/m³ and 96 kg/m³ bio-soluble glass wool, tissue backed, 320gsm Sonatex™ / Sonaris™ acoustic laminate finish.

Key Features

NRC 1.00, 50mm thick panel provides superior sound ab-sorption at low to high frequencies in either direct fix over plasterboard or as a suspended ceiling
CAC 30 as standard
Large panels up to 1200 x 2400mm provide for a cleaner look with fewer panel joins compared to standard 600 x 1200mm size
Can be suspended or directly fixed over plasterboard linings to reduce reflections from hard surfaces
Fire Group 1-S
Ministry of Education DQLS V3.1 2024 compliant solution.
Green Tag certified Level A, low VOC, core contains 80% recycled post consumer waste glass
Made in NZ, meaning short lead times
Packaging take back and product stewardship renew and reuse program
Panels available with temporary protective foil covering to keep the panels clean during installation — ideal for service panels
Light weight for seismic areas, easy to work and trim
Optional Sonatex Hygiene laminate facing.

Ranges

Thermal Triton Sonaris Hygienic Decorative

NZ Made

NZ-Owned Business

Pre-Consumer Recycled Content

Scope of Use

Triton 50™ is an ideal retrofit acoustic panel for call centres, open plan offices, halls, classrooms, libraries, classrooms, offices, community halls when applied directly over plasterboard in large sheets or as a suspended grid and panel ceiling.

NRC 1.00, 50mm thick panel provides superior sound ab-sorption at low to high frequencies in either direct fix over plasterboard or as a suspended ceiling
Large panels up to 1200 x 2400mm provide for a cleaner look with fewer panel joins compared to standard 600 x 1200mm size
Can be suspended or directly fixed over plasterboard linings to reduce reflections from hard surfaces
Ideal for service panels
Light weight for seismic areas

Limitations on Use

Shall not commence until the building is water tight and dry
Light fittings shall be independently supported
Back Loading — Max. 1.5 kg/m², point loads shall be independently supported
Use hold down clips in areas of wind uplift
Not for air return plenums
Use Rondo Donn DXW T38 wide faced grid for large module panels (1200 x 1800/2400/3000mm)
Max 99% R/H at 45°C

Statement of Building Code Compliance

NZ Building Act

This product is not subject to a warning or ban under Section 26.

NZ Building Code Compliance:

B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
C3 Fire – Clause C/AS2 4.12.1: Asona Triton 50 has a Fire Material Group Number 1-S by NZBC Building Product Specification Parts 8.5.4 or 8.5.5, tested in accordance with ISO 9705 or ISO 5660. (NCC BCA C1.10 clause 4, spec A2.4 clause 4. Group 1)

In-Service History

Multiple projects

Other Performance Attributes

Global Green Tag Certified, Class A, core contains 80% recycled local glass waste, low VOC <0.005 Mg/M²/hr per ASTM D5116.
Packaging return, panel recycle and renew programs
Light Reflectance — 85% per BS8493:2008, White
Thermal Resistance — R 1.47 m²°C/W
NRC 1.00
CAC 30 as standard
Packaging take back and reuse scheme available
Optional Sonatex Hygiene laminate facing.
