PaneLux® A1 solid aluminium panels are suitable for use as an external wall cladding material when incorporated into a compliant drained and ventilated façade system.

Suitable for projects seeking solid aluminium façade materials where aluminium composite panels are not preferred.

Suitable for buildings constructed in accordance with:

• NZS 3604:2011 Timber framed buildings
• NZS 3404:2009 Part 1 and NASH Standard Part 2:2019 for light steel framed buildings
• Specific engineering design (SED) in accordance with NZBC B1/VM1 by a Chartered Professional Engineer
• Suitable for buildings within the scope limitations of NZBC Acceptable Solution E2/AS1 (Third Edition Amendment 10) for buildings with a risk score up to 20.
• Suitable for installation in all wind zones up to and including Extra High as defined in NZS 3604:2011.
• The façade system must incorporate a drained and ventilated cavity.
• In Extra High wind zones a rigid air barrier must be installed. In lower wind zones either a rigid air barrier or flexible building wrap may be used.
• Suitable for use in all exposure zones as defined in NZS 3604:2011. Additional consideration should be given to areas identified as adverse microclimates.
• Non combustible packers must be used where the cladding is installed within 1 m of the relevant boundary.
• PaneLux A1 panels do not contain polymer or composite core materials.

Show more

PaneLux® A1 Solid Aluminium cladding panels, when incorporated into a compliant façade system and designed, installed and maintained in accordance with Mulford New Zealand technical literature and project specific engineering where required, may contribute to compliance with the following clauses of the New Zealand Building Code.

• Clause B1 Structure Performance B1.3.1, B1.3.2, B1.3.3(a, h)
• Clause B2 Durability Performance B2.3.1(b)
• Clause C3 Fire Affecting Areas Beyond the Fire Source Performance C3.4(a) and C3.7(a)
• Clause E2 External Moisture Performance E2.3.2, E2.3.5, E2.3.7
• Clause F2 Hazardous Building Materials Performance F2.3.1

Supporting evidence includes material fire performance testing, façade system testing undertaken in accordance with AS/NZS 4284, and supporting technical documentation including the PaneLux A1 Design Guide and Processing & Technical Data Guide.
