• Residential and commercial applications
• Up to 4.5m wide
• Options for manual operation, motorisation, remote control and sensors

Size & Installation:

• Italia Box awnings can easily be installed directly onto the window architrave, the wall, or under the eaves
• Standard projection: 1m and 1.4m. Smaller projections available on request; to a minimum of 0.6m
• Width maximum: 4.5m
• Width minimum: 1.0m
• Standard angle 90° — drop arms can be lowered up to 140°

Operation:

• Manual operation via hand crank:
  • Crank handles available in 1m, 1.5m, 1.8m, or 2.2m to suit the location requirements for manual operation
• Optional motorisation:
  • Range of motor options depending on awning size
  • Controls via either hard wired or remote control (handheld or wall mounted)
  • Optional sensors for sun, wind, and rain

• Maximum wind suitability is 35 km/h.
• For installations near coastal areas it is recommended to wash the components and rails 3 to 4 times a year.
• Follow recommended installation of two brackets for awnings up to 2m wide and one additional bracket for every 1.5m in width thereafter.
• Motors must be installed by a registered electrician.

Window Treatments has nationwide service coverage and has been operating since 1984.

• Manufactured from anti‑corrosive, highly durable materials.
• Fabric options include colours and fabrics with UV and light fastness protection.
• Somfy motor options all with IP 44 rating. See Specification Sheet for full performance information.

Warranty & Maintenance:

• 3 year warranty.
• Coastal maintenance recommendation: wash components and rails with fresh water 3–4 times per year.
