Sanivite+ Grey Water Pump
Description

Sanivite+ is a quiet and compact grey water pump for domestic applications.  Ideal for kitchen, bath, outdoor BBQ kitchen or laundry. Sanivite+ has up to four inlet connections making it the ideal solution for installing multiple plumbing fixtures.

Saniflo grey water pumps allow sanitary fixtures to be installed in areas where access to waste water pipes and conventional gravity drainage is limited, increasing the design possibilities for installing additional facilities in existing buildings.

Key Features
  • Sanivite+ has up to four inlet connections
  • Only for domestic application
  • Powerful, quiet pump
  • Compact for concealed installation
  • Low activation level (95 mm)
  • Carbon filter included to neutralise odours
  • Will handle up to 60°C for short periods (5 minutes)
Scope of Use

Sanivite+ is a grey water pump for domestic applications:

  • Ideal for kitchen, bath, outdoor BBQ kitchen, or laundry
  • Up to 4 inlets for multiple fixtures
  • Hand basin, bath, kitchen sink, washing machine, dishwasher
  • Compact for discrete installation
  • Can pump up to 5m in height, or  50m length — refer to data sheet
  • Flow rate of 110 L/min
  • Inlet pipework: 40mm. Discharge pipework: 25mm
Limitations on Use
  • Must be installed by a licensed plumber
  • All horizontal pipework requires a minimum of 1:100 fall
  • Working temperature of 35°C — will handle up to 60°C for short periods (5 minutes)
  • For other applications see Product Selection Grid
Statement of Building Code Compliance

In opinion of Saniflo this product meets the following provisions of the NZBC:

  • Clause B2 DURABILITY: Performance B2.3.1 [a] not less than 50 years, and B2.3.1 [b] 15 years, and B2.3.2. The Sanivite meets this requirement
  • Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Sanivite meets this requirement and does not present a health hazard to People
  • Clause G13 FOUL WATER: Performance G13.3.1 and G13.3.2. Sanivite meets these requirements

Producer Statement available. Project specific compliance statements are available on request.

In-Service History

The Saniflo SFA Company is the inventor of the macerator concept, with waste solution products successfully deployed around the world for the past 10 years.

Other Performance Attributes
  • Watermark Certificate WMTS 106: 2019 Certificate number: 23048
  • This product meets AS/NZS 3500.1:2018
  • IP rating 44

Warranty Conditions

  • This device is guaranteed for 2 years from the date of purchase and is subject to:
    • NZ CG Act 1993 if used for personal, domestic or household use
    • Installation in strict compliance with manufacturers installation manual in the product box
  • This warranty does not cover the following which remain at the risk, cost and responsibility of the owner:
    • Costs of travel and transport or insurance of the device
    • Device installed outside 50km radius from an accredited Saniflo Agents Office
    • All Costs necessary to safely access and replace the installed device including costs of additional plant equipment, materials. handling and/or safety equipment
  • This warranty is not transferable
  • This warranty shall not apply when the product is sold or installed outside New Zealand
Documents
Drawings on BIMobject
Data Sheet: Sanivite+
Installation: Sanivite+

04.17

Saniflo Design Guide
Saniflo Product Selection Grid

Saniflo has a solution to overcome those situations where drainage is a problem — allowing freedom of design without the cost and inconvenience of moving sewer pipes.
