InteriorInterior
Installing Natural Stone, Marble, Granite, All Other Natural Stone
Description

A complete system for installing natural stone, including marble, granite and other stones, in residential and commercial interiors. Addresses staining, discolouration and moisture sensitivity with correct substrate preparation, optional moisture control or waterproofing in wet zones, stone-safe adhesives and grouts, and a defined care pathway.

Pre-sealing with Fila PW10 on faces and edges, and backs where required, is strongly recommended to limit absorption, reduce picture framing risk and ease post-installation cleaning.

Key Features
  • Confirms stone type and moisture sensitivity, with specific allowances for translucent, resin-backed or mesh-backed stone.
  • Defines substrate planeness and stiffness targets, correcting with bonded screeds or self-levelling compounds rather than adhesive build.
  • Requires full-spread trowelling for uniform contact, no spot fixing, and back-buttering where needed on larger formats.
  • Specifies pre-sealing before install using Fila PW10 to help resist staining and limit grout or adhesive residues.
  • Places waterproofing directly under stone in internal wet areas and uses moisture vapour control in dry zones presenting borderline readings.
  • Matches primers to substrate porosity and selects adhesives and grouts compatible with the stone and the exposure class.
  • Provides movement joint layout rules and minimum joint widths, with perimeters and intermediate joints shown on the drawings.
NZ-Owned Business
NZ-Owned Business
Scope of Use
  • Interior floors and walls in residential and commercial buildings, including internal wet areas when detailed with an approved membrane.
  • Suitable substrates include cured concrete and cementitious screeds brought to tolerance for planeness and rigidity.
  • Plane correction and regrading can be achieved with bonded screeds or self-levelling compounds before stone fixing.
  • Adhesives are selected to stone type, size and sensitivity to moisture.
  • Grouting is selected to the cleaning regime and exposure, with cement or epoxy options.
  • Movement joints are required at perimeters, over structural joints and at centres per design. Typical spacing is 6m on internal floors, or 4.5m where sun-exposed, and 3 to 4.5m on walls, with a 15 to 20 percent reduction when flexible adhesives are used.
  • For project-specific detailing, quantities and programme advice, speak with the Surtec Technical Team via the EBOSS Enquire button.
Limitations on Use
  • Not for exterior facades, decks or immersed environments unless separately designed and detailed.
  • Not a substitute for structural crack control or negative-side waterproofing.
  • Substrates must meet planeness, strength and deflection criteria before stone installation.
  • Moisture vapour barriers in dry zones are not waterproof membranes.
  • Movement joints must not be omitted or bridged and must be carried through finishes where present.
  • If the project includes substrate movement or cracking, tanking, structural details, pools, facades, balconies or decks, heated floors or chemical exposure, speak with the Surtec Technical Team before specifying.
Statement of Building Code Compliance
  • When designed and installed in accordance with this system and good trade practice, the system can contribute to compliance with the New Zealand Building Code, including B2 Durability and F2 Hazardous Building Materials.
  • Internal wet areas, when detailed with a BRANZ Appraised membrane from our system, can contribute to E3 Internal Moisture.
  • Industry references used in practice include AS 3958 Tiling, AS 3740 Internal Wet Areas, AS 4858 Membranes, the IWAM Code of Practice and the Tile Association of New Zealand Best Practice Guide.
In-Service History

Technokolla stone installation systems distributed by Surtec are used across New Zealand and internationally in residential and commercial interiors including kitchens, bathrooms, lobbies and hospitality spaces. Components are selected to EN and ISO classifications for predictable, repeatable outcomes with natural stone.

Other Performance Attributes
  • Stone-appropriate adhesives provide high wetting, non-slip placement and deformability options to reduce stress transfer.
  • Cement grout offers a fine finish with colourfast shades and antibacterial additives for hygiene.
  • Epoxy grout provides dense, low-absorption joints with chemical and stain resistance for demanding cleaning regimes.
  • A defined care pathway using Fila Solutions neutral pH routine cleaners, periodic deep cleaners and, where suitable, penetrating protection helps preserve appearance and reduce maintenance effort.
BRANZ Appraised
BRANZ Appraised
Documents
Installation: Natural Stone
Installing Natural Stone Marble, Granite

250901

System Specification – Moisture Senstive Stone Installation

250901

System Specification – Natural Stone Installation (External)

250901

Technokolla’s tiling and waterproofing systems offer BRANZ-appraised performance for NZ residential & commercial projects, complying with NZBC, and IWAM best practice; backed by a 15 year warranty.
