Quadzero
Description

Quadzero is a high performance, foil-faced, mass-loaded vinyl noise barrier, offering superior acoustic transmission loss and low spread of flame surface covering.

Quadzero was developed to meet market noise reduction requirements in the domestic, commercial, industrial and OEM sectors.

Key Features
  • Low cost and long lasting with over 40 years’ industry use
  • No ozone depleting substances generated during manufacture
  • Complies to IMO 653.16 - low spread of flame
  • Complies to AS1530.3 & BS 467.6/7 building codes
  • Free from lead, odour-producing oils and bitumen
  • Easily installed in awkward places
  • The foil facing also makes it easy to bond onto other substrates using matching Tape ALR adhesive or equivalent
  • Easy to cut, sew, tape and mechanically fasten into position
  • Resistant to water, oil and natural weather conditions
  • Tear resistant with high tensile strength. Ability to be suspended in lengths of up to 5 metres
  • Available in various weights, widths and roll lengths
  • Available with various laminates such as foams, polyesters and fibreglass
Categories / Ranges
Acoustic Insulation
Scope of Use
  • Inside cavities or over lightweight wall, ceiling and floor constructions
  • Ideal for home theatres, office partitions, meeting rooms
  • Over roof joists to reduce aircraft, rail and traffic noise
  • Applied between the plenum chamber of a floor slab, roof and adjoining partition walls
  • Installed around the outside of metal air ducts to reduce noise break-out
  • Wrapped around noisy pipes, e.g. fluid or gas pulsation in chemical, petrochemical and waste water treatment plants
  • Wrapped around valves and fan casings
  • Automotive firewalls to reduce engine and road noise transmitting through the structure
  • Rail carriages for under floor insulation to reduce track and braking noise
Documents
Data Sheet
Accreditation
Product Brochure

Pyrotek Noise Control products are designed to provide high-level acoustic performance in commercial and industrial buildings.
