Leaf Type:

• Core: Solid Core
• Cappings: Pacific aluminium extrusion capping to vertical edges.
• Facings: Medium Density Fibreboard with concealed sheet lead lining.
• Leaf Thickness: Nominal 47mm thick.
• Leaf Weight: 39kg/m² for 1mm lead equivalent door.
• Leaf Sizes: The X-Ray Barrier door set is available for manufacture to any practical size to suit client requirements. Thought should be given to the available sizes of leaf facings so that there are no visible joins, and so that the structural integrity of the door is not compromised.

Leaf Facings:

The facings listed below are available for the X-Ray Barrier door set

• MDF
• Oil Tempered Hardboard
• Hardboard
• Plywood
• Timber Veneers
• Metal Sheet, mild or stainless (0.6 - 1.0mm)
• Aluminium Sheet (0.3 - 1.0mm)
• High Pressure Laminate up to 1.5mm thick (eg: Laminex, Formica)
• Sheet Vinyl (1.25 - 2mm)

Leaf Edges:

• The Pacific X-Ray Barrier door set includes aluminium extrusion capping to the two long edges. Standard finish is natural anodised (silver). Other leaf edges are available upon request.

Vision Panels

Vision panels for X-Ray Barrier door sets are available with glazing that is rated to the lead thickness of the door leaf. Consideration should be given to the fire rating of the door set (if applicable).
