Typical applications:

·         External door to a secure warehouse

·         Staff or property protection

·         Secure Plant Room

·         Embassies

·         Cash Handling Facilities

·         Pharmacy/Drug Store

For further information on this product, visit: https://www.pacificdoors.co.nz/products/security/security-doors/5te

Security Testing

The door set is rated to level 5 of the European ENV 1627-30:1999 “Windows, doors, shutters – Burglar resistance”, which is the second highest level of the standard. The testing incorporates a static load test with applied loads of up to 1500 kg as well as manual attack for 15 minutes with a range of hand tools and power tools.

Ballistic Testing

The door set has been successfully tested to AS/NZS 2343:1997 “Bullet-resistant panels and elements” with ratings of G2 and S0. G2 is the most severe handgun rating in the standard and constitutes an attack with a 44-calibre magnum revolver, while S0 corresponds to a 12-gauge shotgun using 32g high velocity shot.

Explosive Blast Testing

The Pacific 5TE is tested to level EXR 3 of EN 13124:2004 “Windows, doors and shutters – Explosion resistance”.

An explosive charge of 12 kg TNT was detonated 5.5 metres away from the door.

Thermal Insulation

This door leaf has a thermal insulation rating (R-value) of 0.029 Km2/W.
