• Steel framed VP60 door sets may only be installed in walls of minimum stud size ex 100x50mm (Gib® Fire Rated Systems).
• Standard frames are three-sided only with no sill. Four-sided frames and/or custom sills may be available on request.
• Door sets with leafs larger than 2700 x 1200 are not intended for frequent use, we recommend they be typically either held open or closed with compliant hardware in normal operation.
• Metal cappings are not available for timber framed doorsets or doors into Speedwall or James Hardie.Timber sills are not available on fire doorsets.
• Circular vision panels are not possible with Pyrobel glazing.
• Pyrobel is not suitable for exterior doors.
• Circular vision panels are not currently offered for this product.

Acoustic Performance

An acoustic rating of STC 31 (Rw 32) is available for ply / MDF faced doors and STC 36 (Rw 38) for steel face doors.

Tested acoustic seals are Lorient LAS1212 perimeter seals and LAS8007si drop seal.

Pair doors are acoustic tested with J-section meeting stile with one line of Schlegel QEZ6.8 acoustic seal.

Vision panels are not acoustic tested. Pyrobel glazing is rated Rw 39 from the supplier, Pyran S is Rw 31.

Thermal insulation

This door leaf has a thermal insulation rating (R-value) of 0.645 Km2/W.
