Please note that the maximum leaf width shown above is measured per door leaf.

The ‘sm’ above denotes that the door is available as a smoke control door set.

Minimum width for a fire door leaf is governed by the need to fit a compliant closer. Typically, 400 mm is the practical minimum.

Meets NZS4520.2010 standard

Security Testing

The SPS1 door set was subjected to 50 impacts from a 200kg cement-filled bag at 4.8m/s, in the direction of opening of the door. The door was able to be opened at the end of the test and was substantially undamaged.

Thermal Insulation

This door leaf has a thermal insulation rating (R-value) of 0.615 Km2/W.

Ballistic Testing

The SPS1-FR door set has been successfully tested to AS 2343:1984 “Bullet-resistant panels for interior use” with ratings of:

• G1 .357 Magnum
• S0 Shotgun 12 gauge SG shot
