• The thickness of the window frame is 50 mm with an approximate glazed weight of 35 kg/m².
• The window is tested to AS/NZS 4284:2008 – “Testing of building facades” and complies with requirements of NZS 4211:2008 – “Specification for performance of windows” up to and including the Extra High Wind Zone.

Wall Types:

• The Pacific Steel Fire Window -/120/- is suitable for installation in timber or steel stud plasterboard walls and masonry fire-rated walls. Walls to be fire rated to a minimum -/120/- by others.
• The standard installation method for steel or timber stud walls is by 12g screws at max. 450 mm centres.
• The standard for Masonry installation is M8 Excalibur screwbolts (or similar) at max. 450 mm centres. No fasteners are exposed to weather or attack face.

Finish:

• Standard preparation for interior use is powder coating.
• Standard preparation for exterior use is sandblasting followed by zinc arc spray (15-year weatherability grade) to the frame.
• Unit can be delivered with a powder coat finish or primed, ready to paint.

• The maximum allowed clear view is 2176 high x 1176mm wide. Maximum overall height is 3782mm. Multiple panes may be joined horizontally by mullions.



• Tested to AS/NZS 4284:2008 and NZS 4211:2008
• Complies with NZS 4232.2:1988 and meets NZBC C/AS2
• The window is tested to AS/NZS 4284:2008 – “Testing of building facades” and complies with requirements of NZS 4211:2008 – “Specification for performance of windows” up to and including the Extra High Wind Zone.

• The glazing used in this window has a thermal insulation rating (R-value) of:
  • Pyran S: 0.172 Km2/W
