Vision Panels

Vision panels for the Hospital door set are available with anodised aluminium the standard beading, and can be of any practical size within the door leaf provided that there is a minimum 150mm perimeter rail as shown below.

Vision panels are available double-glazed with integral venetian blinds including a controller fitted into the door face.

Glazing can be of any type to suit your requirement.

Leaf Type

Core: Solid Core

Capping: Pacific anodised aluminium extrusion capping to vertical edges.

Facings: High Pressure Laminate (e.g. Formica or HPL) or sheet Vinyl (preferably flooring grade) over Medium Density Fibreboard.

Leaf Thickness: Nominal 47mm thick.

Leaf Sizes: The Hospital door set is available for manufacture to any practical size to suit client requirements. Thought should be given to the available sizes of leaf facings so that there are no visible joins, and so that the structural integrity of the door is not compromised.

Leaf Facings

The facings listed below are available for the Pacific Hospital door set

·         MDF

·         Oil Tempered Hardboard

·         Hardboard

·         Plywood

·         Timber Veneers

·         Metal Sheet, mild or stainless (0.6 - 1.0mm)

·         Aluminium Sheet (0.3 - 1.0mm)

·         High Pressure Laminate up to 1.5mm thick (eg: Laminex, Formica)

·         Sheet Vinyl (1.25 - 2mm)
