Pacific FW120 Fire Window
Pacific Doors
All products
Screenshot 2025 06 25 123941
Description

The Pacific FW120 is a fire window system which is fire-resisting glazing as defined in the New Zealand Building Code Acceptable Solutions C/AS2 to C/AS6.

The system consists of non-opening (fixed) glazing with Pyroceram clear glass factory-fitted into a steel frame for interior use.

Key Features
  • 120min fire rating
  • Single glazed
  • 2 glass options
  • 2 frame options
  • Suitable for interior use only
  • Compatible with timber stud, steel stud and masonry wall
  • Complies with NZS 4232.2:1988 and meets NZBC C/AS2
Categories
Fire-Rated Interior Doors, Windows and Partitions
Scope of Use
  • Suitable for interior use only.
  • Compatible with timber stud, steel stud and masonry wall.
  • Approximate window weight is 38 kg/m².
  • Precast concrete (100mm thickness) or grouted blockwork (190mm thickness).
  • Non-load bearing timber stud partitions of minimum specifications GBT60a or GBT60b. Note that steel framed VP60 door sets may only be installed in walls of minimum stud size 100x50mm nominal (GIB® Fire Rated Systems 1997).
  • Non-load bearing steel stud partitions of minimum specification GBS90 (timber framed doors) or GBS60 (Steel framed doors) (Gib® Fire Rated Systems 1997).
Limitations on Use
  • This window is not suited to exterior conditions.
Statement of Building Code Compliance
  • Complies with NZS 4232.2:1988 and meets NZBC C/AS2
  • The Pacific FW120 is a fire window system which is fire resisting glazing as defined in the New Zealand Building Code Acceptable Solutions C/AS2 to C/AS6.
Documents
Data Sheet

6/25/25

pdf
Additional Information
URL

Pacific Doors specialise in the bespoke manufacture of high strength, performance door and window systems for fire, acoustic, security, hospital, ballistic and commercial purposes.
