Pacific ARMASHIELD Ballistic Door Set
Description

Pacific ARMASHIELD Ballistic Door Set

Pacific Doors offers a range of Security door sets that have been named the 'Protector' series.

These door sets are designed with the intention of 'Keeping Out' any intruder on the basis that they may try to attain entry using a variety of methods such as guns, explosives, or hand tools. Many of these door sets come with a certified fire rating to provide an additional level of security.

Description



The Pacific Armashield Ballistic door set is an all-steel security door set, hung in a steel frame. The door set is designed for resistance to attack by handguns and rifles to either face. Test results refer to both single leaf and pair hinged door sets.

Key Features

·         Single or pair leaf only

·         Multipoint locking system

·         Suitable for both interior and sheltered exterior use

·         Compatible with timber stud and masonry wall



·         Explosive blast tested to AS/NZS 2343

NZ Made
NZ Made
Scope of Use

A version of the Armashield is available tested to R2 rating.



The thickness of the Armashield door leaf is 48mm (52mm for R1 & R2 rating). Leaf weight is approximately 80kg/m2 (90kg/m2 for R1 & R2).

In-Service History

Thermal Insulation



This door leaf has a thermal insulation rating (R-value) of 0.029 Km2/W.

Other Performance Attributes

Security Testing

Please talk to a Pacific Doors representative if you require a combination of security and ballistic resistance.

Explosive Blast Testing



The Pacific ARMASHIELD Ballistic doorset can be delivered with explosive blast resistance with limitations on configurations and hardware. Please see our ARMASHIELD Blast datasheet for more information.

Documents
Data Sheet

7/2/25
