·         Remote secure stations

·         Armouries

·         Store rooms with high value or sensitive material

Security Testing

The door set is rated to level 6 of the European ENV 1627-30:1999 “Windows, doors, shutters – Burglar resistance” which is the highest level of the standard. The testing incorporates a static load test with applied loads of up to 1500 kg as well as manual attack for 20 minutes with a range of hand tools and power tools.

Ballistic Testing

The 6ST door set has been successfully tested to AS/NZS 2343:1997 “Bullet-resistant panels and elements” with ratings of R2, R1, and S1. R2 is the most severe rating in the standard.

• R2 7.62mm calibre rifle
• R1 5.56mm calibre rifle
• S1 Shotgun 12 gauge 28g single slug

Explosive Blast Testing

The Pacific 6ST is tested to level EXR 4 of EN 13124:2004 “Windows, doors and shutters – Explosion resistance”.

An explosive charge of 12 kg TNT was detonated 4 metres away from the door.

Thermal Insulation

This door leaf has a thermal insulation rating (R-value) of 0.615 Km2/W.
