Leaf Type

Core: Solid Core

Cappings: Pacific anodised aluminium extrusion capping to long edges.

Facings: High Pressure Laminate (e.g. Formica or HPL) or sheet Vinyl (preferably flooring grade) over Medium Density Fibreboard.

Leaf Thickness: Nominal 47mm thick.

Leaf Sizes: The Emergency Access door set is available for manufacture to any practical size to suit client requirements. Thought should be given to the available sizes of leaf facings so that there are no visible joins, and so that the structural integrity of the door is not compromised.

Leaf Facings

The facings listed below are available for the Emergency Access door set

·         MDF

·         Oil Tempered Hardboard

·         Hardboard

·         Plywood

·         Timber Veneers

·         Metal Sheet, mild or stainless (0.6 - 1.0mm)

·         Aluminium Sheet (0.3 - 1.0mm)

·         High Pressure Laminate up to 1.5mm thick (eg: Laminex, Formica)

·         Sheet Vinyl (1.25 - 2mm)
