Acrylic Laminate Panels
Description

Compac Panels Acrylic is a premium range of high-gloss and matte decorative panels engineered for high-end interior cabinetry, joinery, and vertical feature wall linings. Manufactured in Australia using TruColor coextruded multilayer UV barrier technology, the acrylic laminate layer is factory-pressed onto specified timber-based substrates at Compac Panels' manufacturing facility in Dargaville, New Zealand.

The collection offers 30 coextruded solid colour variations across gloss and matte finishes, delivering strong colour consistency and UV resistance. Acrylic panels are pressed to order with a standard production lead time of 5 working days. Matching edge banding (including unglued, pre-glued, and laser edge options) and cover caps are available for clean joinery execution.Substrate options and sheet formats include:

  • MDF (Medium Density Fibreboard): Available in 2440x1220mm sheets in thicknesses ranging from 3mm up to 25mm.
  • HMR-MDF (Highly Moisture Resistant): Available in 2440x1220mm sheets in selected joinery thicknesses (including 16mm, 18mm, and 25mm).
  • INDO Ply: Available in 2440x1220mm sheets in thicknesses including 9mm, 12mm, 16mm, and 18mm.
  • Birch Ply: Available in 2440x1220mm sheets in 18mm thickness.
  • Configurations: Available in single-sided or double-sided laminate options.
Key Features
  • TruColor Multilayer UV Technology: Engineered with advanced co-extruded multilayer UV barrier protection to maintain colour vibrancy and prevent yellowing or fading over time.
  • High-Gloss & Soft-Matte Aesthetics: Provides high-clarity reflective gloss finishes or smooth, low-sheen matte surfaces for modern architectural interiors.
  • Clean Workshop Processing: Formulated for straightforward processing and fabrication on standard woodworking, cutting, edge-banding, and CNC equipment .
  • Screw-Holding Stability: Utilises New Zealand radiata pine fibres for MDF substrates, offering structural panel stability and strong screw retention.
  • Matching Joinery Accessories: Complete range of colour-matched ABS/laser edge bands and cover caps to ensure continuous, seamless panel edges.
Scope of Use
  • Commercial Fit-outs & Office Joinery: Suitable for commercial office joinery, reception desks, feature wall paneling, and storage units in low-to-medium impact commercial environments.
  • Hospitality Interiors: Recommended for vertical feature panels, decorative wall linings, and fitted cabinetry in hotels, cafes, and restaurant interiors.
  • Residential Kitchen & Bathroom Cabinetry: Ideal for kitchen cabinet doors, drawer fronts, pantry units, vanity fronts, and laundry joinery.
  • Bespoke Furniture & Wardrobes: Suitable for custom furniture pieces, bedroom wardrobes, and built-in cabinetry solutions.
Limitations on Use
  • Interior Vertical Applications Only: Intended solely for interior vertical joinery and wall linings; not designed for horizontal kitchen benchtops, worktops, or heavy floor wear applications.
  • Non-Structural: Cannot be used as structural elements in wall, ceiling, or floor assemblies.
  • Moisture & Steam Constraints: Water and moisture resistant, but not waterproof; must not be exposed to direct water contact (e.g. inside shower enclosures) or persistent high steam/saturation
  • Thermal Proximity: Excessive heat above 75°C can damage the surface; required minimum clearances must be maintained from major heat sources like cooktops.
Statement of Building Code Compliance

Compac Panels Acrylic, if designed, used, installed, and maintained in accordance with the conditions of Compac Panels' technical literature, will comply with, or contribute to compliance with, the following performance provisions of the NZ Building Code:

  • Clause B2 DURABILITY: Performance B2.3.1(c) 5 years.
  • Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.

Contribution to Compliance:

  • B2.3.1(c): Supported by a 10-year manufacturer's warranty against faulty materials or lamination defects when handled, fabricated, and installed according to Compac Panels guidelines
  • F2.3.1: New Zealand-manufactured MDF substrate meets Environmental Choice standards for formaldehyde emission levels of E0 (< 0.5mg/L), making it safe to machine and install.
Other Performance Attributes
  • Environmental Choice Licensed Substrate: Standard MDF substrate conforms to E0 formaldehyde emission standards (< 0.5mg/L)
  • FSC Certified Wood: Core wood fibers are sourced from FSC-certified, sustainably harvested New Zealand radiata pine forests
  • Renewable Energy Manufacturing: Laminated in a New Zealand facility running on 100% electricity sourced from the national grid (82% renewable energy)
  • Sustainable Waste Management: Cardboard packaging is recycled locally and timber waste offcuts are diverted to agricultural composting

Warranty & Maintenance

  • Supported by a 10-year manufacturer's warranty against material defect or faulty workmanship when specified and installed in accordance with technical recommendations.
  • Clean with a warm, damp microfibre cloth and wipe dry immediately. Mild household surface cleaner or dishwashing liquid can be used for persistent marks.
  • Do not clean with abrasive powders, bleach, scouring pads, sandpaper, or harsh solvent thinners as these will permanently damage the surface and void the warranty.
Documents
Specifications Sheet: Acrylic
Material Safety Data Sheet: Acrylic
Warranty: Acrylic
Colour Range & Product Page: Acrylic
