Triton Duo 35
Description

Triton Duo 35™ is a New Zealand made mass loaded 35mm thick composite ceiling panel designed to provide high attenuation of transmitted noise plus absorption to control reverberation times. Panels are available in a range of decorative finishes.

Will attenuate rain noise under metal roofs, plenum noise from A/C ducts, provides room to room privacy with ceiling over partition heads and will reduce reverberation times in office, classrooms, corridors, meeting rooms, etc.

Composition

Manufactured in NZ from 25 mm 48 kg/m³ bio-soluble glass fibre core with a high mass 10mm plasterboard attenuator backer, 320gsm Sonatex™ / Sonaris™ acoustic laminate finishes.

Key Features
  • High mass attenuator backer, STC 20 dB, CAC 44 for attenuation of transmitted noise. Ideal under metal roofs
  • Class C sound absorption, NRC 0.75, ∂W 0.60 for control of background noise & reverberation times
  • Fire group 1-S
  • Broad range of Sonatex and Sonaris perforated acoustic laminate finishes for design freedom
  • Service panels available to order with temporary foil overlay to protect service panel decorative finish during installation, remove prior to hand over
  • Fast and easy to install, dimensionally stable
  • Made in NZ, meaning short lead times including replacement parts
  • Packaging take back & reuse scheme available
  • Product stewardship renew and reuse program
  • Green Tag Certified / Level A, low VOC, core contains 80% recycled post consumer waste glass
  • Durable and dimensionally stable in high humidity
Categories
Suspended Ceilings
Ranges
Triton Sonaris
Green Tag Certified
Green Tag Certified
Recycled Content (Pre-Consumer)
Pre-Consumer Recycled Content
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

Triton Duo 35™ is ideal for ceilings under metal roofs to control rain noise, mechanical service noise, buildings near aircraft flight paths, train lines or for private meeting room ceilings.

Suitable for fire exit way and all other sprinklered & non sprinklered buildings.

Limitations on Use
  • Not for exterior use
  • Installation shall not commence until the building is watertight and dry
  • Light fittings shall be independently supported
  • Backloading max. 1.5 kg/m², point loads shall be independently supported
  • Max 99% R/H at 45°C
  • Use hold down clips in areas for seismic or wind uplift
  • Not for air return plenums
Statement of Building Code Compliance
  • Fire Reaction — NZBC verification method C/VM2 material group number: 1-S. Suitable for fire exit way and all other sprinklered & non sprinklered buildings
  • Clause B2 — durability, 5 years
In-Service History

Multiple national application including schools

Other Performance Attributes
  • Light Reflectance - 85% per BS8493:2008, White
  • Very high sound absorption rating to control reverberation, NRC 0.75
  • High sound attenuation, CAC 44, STC 20
  • Green Tag Certified level A, low VOC, core contains 80% recycled post consumer waste glass
  • Low formaldehyde < 0.05 gm
  • Product stewardship renew and reuse program available
  • Packaging take back and reuse scheme available
Independent Assessment
Independent Assessment
Test Results
Test Results
Documents
Asona Triton Duo 35

23.12

Environmental Information - GreenTag Level A

230413

Environmental Information - GreenTag Level B

22-04

Maintenance: Triton Range
Warranty

Asona Ltd are a manufacturer, distributor and installer of acoustic and decorative ceiling and wall panels.
