• CoreClad panels are for use as external cladding
• In wind zones up to extra high, as defined in NZS 3604:2011 or to a design wind pressure (ULS) of 2.5kPa
• In all corrosion zones as defined in NZS 3604:2011
• In conjunction with a primary structure that complies with the NZ Building Code, or where the designer and/or installer has established that the existing structure is suitable for the intended building work
• CoreClad may be direct fixed or installed over a drained, ventilated cavity

Show more

If designed, installed and maintained in accordance with all IBUILT requirements, CoreClad will comply with or contribute to compliance with the following performance claims:

• B1 Structure: B1.3.1, B1.3.2, B1.3.3 (a, b, f, h, j, m, q), B1.3.4 (a, b, c, d, e)
  Alternative Solution AS/NZS 2269:
  • Plywood manufactured to AS/NZS 2269 is referenced in E2/AS1 for use as a rigid air barrier and external cladding. This implies that plywood to this standard will have the necessary structural integrity for those uses.

• Plywood manufactured to AS/NZS 2269 is referenced in E2/AS1 for use as a rigid air barrier and external cladding. This implies that plywood to this standard will have the necessary structural integrity for those uses.

• B2 Durability: B2.3.1(b), B2.3.1(b)
  Verification Method:
  • B2/VM1: cl1.3 Verification through comparison with a similar material
  • AS/NZS1604.3, para 1.9 requires same characteristic values for penetration & retention as defined in NZS 3640:2003
  • IVS test results show these values are met

• B2/VM1: cl1.3 Verification through comparison with a similar material
• AS/NZS1604.3, para 1.9 requires same characteristic values for penetration & retention as defined in NZS 3640:2003
• IVS test results show these values are met

• E2 External Moisture: E2.3.2, E2.3.5, E2.3.7 (a, b, c)
  Acceptable Solution E2/AS1
  • Installation to section 9.8
• F2 Hazardous Building Materials: F2.3.1
  Alternative Solution
  • PNG Forest Products Treatment Protocol

• Installation to section 9.8

• PNG Forest Products Treatment Protocol

Show more

PASS

PEFC Certified
