• Exterior cladding suitable for coastal conditions
• Up to 60 minute fire resistance rating (FRR) can be achieved when installed as per the James Hardie Fire and Acoustic Design Manual
• Has been tested and complies to the new E2/VM2 Verification method for building facades up to 25m high
• Can be painted any colour, even the darker shades

See BRANZ Appraisal 1211 for full information.

Show more

Corrosion Exposure Zone D

Very High Earthquake Zone

Specific Design Wind Zone

In the opinion of BRANZ, the Axon™ Panel and EasyLap™ Panel Cladding, if designed, used, installed and maintained in accordance with the statements and conditions of Appraisal 1211, will meet the following provisions of the NZBC:

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2 and B1.3.4. The Axon™ Panel and EasyLap™ Panel Cladding meets the requirements for loads arising from self-weight, wind, impact and creep [i.e. B1.3.3 (a), (h), (j) and (q)].
• Clause B2 DURABILITY: Performance B2.3.1 (b) 15 years and B2.3.2. The Axon™ Panel and EasyLap™ Panel Cladding meets these requirements.
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2. The Axon™ Panel and EasyLap™ Panel Cladding meets this requirement.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Axon™ Panel and EasyLap™ Panel Cladding meets this requirement.

See BRANZ Appraisal 1211 for full information.

Show more

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Airborne and Impact Sound

Energy Efficiency

• Provides a traditional weatherboard look — 16mm thick bevel-backed weatherboard
• Linea Weatherboard can be used to achieve bracings
• 30, 60 and 90 minute fire resistance ratings can be achieved when installed as per the current James Hardie Fire and Acoustic Design Manual
• Direct or Cavity fix
• Tongue and groove ends for easy and unflashed off stud jointing
• Exceptional performance in harsh conditions, including coastal environments
• Boards come pre-primed manila white in colour can be painted dark colours

Show more

Corrosion Exposure Zone D

Very High Earthquake Zone

Specific Design Wind Zone

• BRANZ appraised
• CodeMark certified
• Boards have a 25 year product warranty
• 30, 60 and 90 minute fire resistance ratings can be achieved when installed as per the current James Hardie Fire and Acoustic Design Manual
• Exceptional performance in harsh conditions, including coastal environments
• Linea Weatherboard has enhanced stability and can be painted dark colours

Show more

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Energy Efficiency

BRANZ Appraised

CodeMark

• Used to create colourful feature walls, full cladding for new builds, cladding for additions and renovations and internal feature walls
• Suitable for both horizontal and vertical applications
• Ideal for overhangs, protective cantilevers, and other architectural features
• Up to 60 minute fire resistance rating (FRR) can be achieved when installed as per the James Hardie Fire and Acoustic Design Manual
• A vertical jointing option is available to create feature along long walls
• Engineered to stand up to harsh conditions, including coastal conditions
• Can be painted a large variety of colours, even the darker shades

Show more

Corrosion Exposure Zone D

Extra High Wind Zone

The following clauses of the NZBC are applicable to Linea Oblique Weatherboard and it complies with these requirements as explained below;

• Structure B1: Wind load tests have been completed at a NATA accredited James Hardie laboratory and the suitability of its fixings has been verified to meet wind pressure requirement in various wind zones classified in NZS 3604 and meets the requirements of B1.3.1, B1.3.2 and B1.3.4.
• Durability B2: Linea Oblique Weatherboard has been tested at a NATA accredited laboratory in accordance with AS/NZS 2908.2 and meets the durability performance requirements as per B2.3.1(a) and B2.3.2 of this clause.
• Fire Performance C: Linea Oblique Weatherboard has been tested and is classified as non-combustible material and is suitable for use on external walls close to boundaries.
• External Moisture E2: Linea Oblique Weatherboard as per the details published in its technical specification has been tested for weathertightness as per E2/VM1 (as contained within NZBC Clause E2, Third Edition, Amendment 5).
• Hazardous Building Materials F2: Linea Oblique Weatherboard complies with the requirements of F2.3.1 and will not present a health hazard.
• Energy Efficiency H1: Linea Oblique Weatherboardl walls constructed using bulk insulation meets the construction R-Value requirements as per Table 1 of Clause H1.

Show more

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Energy Efficiency

BRANZ Appraised

CodeMark

• For use as an external wall cladding installed either horizontally or vertically in residential and light commercial:
  • Feature walls
  • Full cladding for new builds
  • Cladding for additions and renovations
  • Internal feature walls
  • Ideal for overhangs, protective cantilevers and other architectural features
• Designed to withstand harsh weather and coastal conditions
• Can be painted any colour, even the darker shades

• Feature walls
• Full cladding for new builds
• Cladding for additions and renovations
• Internal feature walls
• Ideal for overhangs, protective cantilevers and other architectural features

Show more

Corrosion Exposure Zone D

Specific Design Wind Zone

In the opinion of BRANZ, Stria™Cladding Horizontal, if designed, used, installed and maintained in accordance with the statements and conditions of this Appraisal, will meet the following provisions of the NZBC:

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2 and B1.3.4. Stria™Cladding Horizontal meets the requirements for loads arising from self-weight, wind, impact and creep [i.e. B1.3.3 (a), (h), (j) and (q)]. See Paragraphs 9.1-9.3.
• Clause B2 DURABILITY: Performance B2.3.1 (b) 15 years, B2.3.1 (c) 5 years and B2.3.2. Stria™ Cladding Horizontal meets these requirements. See Paragraphs 10.1-10.4.
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2. Stria™ Cladding Horizontal meets this requirement. See Paragraphs 14.1-14.5.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Stria™ Cladding Horizontal meets this requirement.

See BRANZ Appraisal No. 1224 for full information

In the opinion of BRANZ, Stria™ Cladding Vertical, if designed, used, installed and maintained in accordance with the statements and conditions of this Appraisal, will meet the following provisions of the NZBC:

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2 and B1.3.4. Stria™ Cladding Vertical meets the requirements for loads arising from self-weight, wind, impact and creep [i.e. B1.3.3 (a), (h), (j) and (q)]. See Paragraphs 9.1-9.3.
• Clause B2 DURABILITY: Performance B2.3.1 (b) 15 years, B2.3.1 (c) 5 years and B2.3.2. Stria™ Cladding Vertical meets these requirements. See Paragraphs 10.1-10.4.
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2. Stria™ Cladding Vertical meets this requirement. See Paragraphs 14.1-14.5.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. Stria™ Cladding Vertical meets this requirement.

See BRANZ Appraisal No. 1225 for full information

The system if designed, used, installed and maintained in accordance with CodeMark number GM-CM30109 will meet the following provisions of the NZBC:

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2, B1.3.4 for the relevant physical conditions of B1.3.3 (a), (f), (h), (j) and (q).
• Clause B2 DURABILITY: Performance B2.3.1(b) 15 years and B2.3.2.
• Clause C3 FIRE AFFECTING AREAS BEYOND THE FIRE SOURCE: Performance C3.5, C3.7
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2, E2.3.5, E2.3.6 and E2.3.7
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.

See CodeMark number GM-CM30109 for full information

Show more

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Energy Efficiency

BRANZ Appraised

CodeMark

• Panel for building facades, fascias and spandrels
• Commercial and residential properties
• Suitable for use on high rise buildings exposed to extreme wind pressure and other weather elements
• Engineered to stand up to harsh conditions, including coastal conditions
• Up to 60 minute fire resistance rating when installed as per the James Hardie Fire and Acoustic Design Manual
• Installed with ExoTec Top Hat system for greater stability and moisture management, up to wind pressure of 5kPa (ULS)

Show more

Corrosion Exposure Zone C

Specific Design Wind Zone

Show more

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Airborne and Impact Sound

Energy Efficiency
