Wall types

The VP Slider may be hung from a concrete or masonry wall either of precast concrete (thickness 100mm minimum) or grouted blockwork (thickness 190mm minimum).

Installation on plasterboard walls no longer compliant as of February 2024.

Thermal insulation

This door leaf has a thermal insulation rating (R-value) of 0.692 Km2/W.

Hardware/Closing Systems

A Standard Track System is supplied with this door set.

Standard Closer

Weight and pulley system with self-closure activated by fusible link in the event of fire.

Electromagnetic Closing Weight System

A weight and pulley system modified for electromagnetic release is available. Closure is on fire/smoke detection activated by sensors (by others) mounted each side of the door set to lintel or ceiling.
