Leaf size

Steel framed smoke control doors include the PFS-4 frame seal. If required, bottom seals can be selected from the Hardware List.

The thickness of the VP120 door leaf is 48mm with an approximate leaf weight of 27kg/m2.

Performance

Acoustical performance

An acoustic rating of STC 31 (Rw 32) is available for ply / MDF faced doors and STC 36 (Rw 38) for steel face doors.

Tested acoustic seals are Lorient LAS1212 perimeter seals and LAS8007si drop seal.

Pair doors are acoustic tested with J-section meeting stile with one line of Schlegel QEZ6.8 acoustic seal.

Vision panels are not acoustic tested.

Thermal insulation

This door leaf has a thermal insulation rating (R-value) of 0.692 Km2/W.
