• The thickness of the window frame is 65mm with an approximate glazed weight of 78 kg/m².
• This is a double-glazed window, especially suited to exterior applications where increased thermal insulation is required.
• Suitable for both interior and exterior
• Compatible with timber stud, steel stud, and masonry wall

Wall Types

• The Pacific PFW30 is suitable for installation in timber or steel stud plasterboard walls and masonry fire-rated walls. Walls to be fire rated to a minimum -/30/30 by others.
• The standard installation method for steel or timber stud walls is by 12g screws at max. 450mm centres.
• The standard for Masonry installation is M8 Excalibur screwbolts (or similar) at max. 450mm centres. No fasteners are exposed to weather or the exterior face.

Finish

• Standard preparation for interior use is powder coating.
• Standard preparation for exterior use is sandblasting followed by zinc arc spray (15-year weatherability grade) to leaf and frame.
• Unit can be delivered with a powder coat finish or primed, ready to paint.

• The maximum allowed clear view is 1376mm high x 2811mm wide. Two vertical lights can be used in a single frame by the inclusion of a transom at mid-height. The maximum allowed total frame height is 2982mm.

• Meets NZS 4211:2008
• Tested to AS/NZS 4284:2008
