IBuilt Structural Plywood

New Zealand Wood Products Ltd

All products

J PLY PREMIUM 5 jpg 0x375 q90 crop smart upscale

J PLY7814 jpg 0x375 q90 crop smart upscale

J PLY DSC8015 jpg 0x375 q90 crop smart upscale

Product Enquiries

Description

IBuilt stock a full range of CD and DD grade plywood in 2.4m lengths. Included in the ply range is StrongPly14® and FloorPly14® structural ply which is New Zealand's strongest rated pine plywood — exclusive to IBuilt.

Applications include flooring, roofing, membrane substrates, internal linings, and structural bracing.

Key Features

F8, F11, F14 stress grade
Tongue and Groove or Straight Edged
A range of thicknesses
Available in 2.4 and 2.7m lengths
H3.2 treated or untreated
Independently certified by the Engineered Wood Products Association of Australasia (EWPAA) to meet the Australian and New Zealand standards: AS/NZS 2269.0:2012
Manufactured from sustainably grown Hoop pine

Ranges

IBuilt — Engineered Wood Products

NZ-Owned Business

Scope of Use

For full scope and limitations, refer to the BPIR.

Limitations on Use

Untreated plywood must not be used externally or in high moisture areas. H3 treated plywood must not be in contact with the ground. It is not recommended to use smooth face plywood as a cladding — refer to IBuilt CoreClad which is manufactured with a textured face veneer specifically for exterior use. Ensure only compatible materials/fixings are in direct contact with CCA treated plywood.

Statement of Building Code Compliance

IBuilt Plywood is manufactured for the New Zealand and Australian markets to meet the Australian and New Zealand standards: AS/NZS 2269.0:2012.

All IBuilt Structural Plywood products meet the requirements of the New Zealand Building Code causes:

B1 Structure — B1.3.1, B1.3.2, B1.3.4(d)
B2 Durability — B2.3.1(a)
F2 Hazardous Building Materials — F2.3.1

Other Performance Attributes

Independently certified by the Engineered Wood Products Association of Australasia (EWPAA) to meet the Australian and New Zealand standards: AS/NZS 2269.0:2012
