Tanova Simplex Kitchen Waste Bin Systems
Description

FIT’s range of Tanova Simplex Kitchen Waste Bin Systems are space-efficient and practical, staying out of sight, yet easily accessed when needed. The Simplex pull out kitchen waste bin range features soft close medium weight ball bearing runners that are sturdy and reliable for residential situations.

Powder coated electro-galv steel frames and baskets are fabricated in Auckland by FIT’s partners at FEL Group.

For kitchen cabinets from 200mm to 450mm, the Simplex pull out kitchen waste bin options include some to attach to a fixed ‘drawer’ front, some to install behind a hinged door. Soft close is standard, with some models also offering push to option.

The Tanova Simplex range is more cost effective than the premium Designer Series range, but nevertheless offers an extensive range of bucket configurations for all needs; from simple 1 bucket units up to 4 bucket models to handle recyclables sorting. 20L and 36L buckets are made in Christchurch at Talbot. Other buckets are imported from Italy.

In addition, there are Simplex Plus options for 400mm and 450mm cabinets plus ‘frame and bucket’ models designed for compatibility with Legrabox drawers (350mm, 450mm 500mm and 600mm cabinets). Tanova Simplex and Simplex Plus kitchen bin systems with 20L and/or 360L buckets carry the official NZ Made licence.

Key Features

Simplex

  • 300mm – 450mm cabinets (external width using 16mm board)
    Heavy duty frame made from 1.2mm gauge steel for strength and durability
  • Simplex models are available mainly with an Umbra Grey frame and charcoal coloured buckets, for practicality. The most popular models are also available in white
  • Runners extend beyond bench top to allow easy removal of rear bucket
  • 45kg carrying-capacity ball-bearing slides
  • Sturdy handles on buckets for easy bin removal and to hold plastic liner-bags in place
  • Strong easy-clean top frame cover which can be used as a shelf if mounted lower in cabinet
  • The top-mounting cover acts as a lid to conceal waste
  • Very quick and easy installation into modular cabinets using 16mm sides
  • Designed with top and side screw fixing points so it fits snugly into standard cabinet sizes and maximises stability
  • Large cutouts in front-mount bracket allows easy fitting of a large range of handle sizes
  • Solid folded and welded door bracket on door type models
  • Slotted screw holes for extra adjustment when fitting drawer front
  • Lock-off point secures drawer front in place once adjusted

Simplex Plus

  • 400mm-450mm cabinets (external width using 16mm board)
  • Super smooth-running drawer slides
  • Runners extend beyond edge of benchtop to allow for easy removal of rear bucket
  • Soft close 30kg carrying capacity
  • Economical, solid and simple bin frame manufactured from 1.0mm gauge steel for added strength and durability
  • Very quick and easy installation into modular cabinets
  • Drawer front connection with 6-way adjustment
  • Compact size maximises space efficiency and its snug fit ensures stability
NZ Made
NZ Made
Scope of Use
  • For residential use in kitchens and sculleries. Also suit use in bathroom vanities.
  • Made for installation into the cabinet
  • Options with up to four buckets — ideal for sorting recycling
  • Simplex:
    • 300mm – 450mm cabinets (external width using 16mm board)
    • 45kg load capacity on runners
  • Simplex Plus:
    • 400mm-450mm cabinets (external width using 16mm board)
    • 30kg load capacity on runners
  • Also 'frame and bucket' systems (300mm, 400mm and 600mm cabinets), some of which are compatible with Legrabox drawers (350mm, 450mm, 500mm and 600mm cabinets)
Limitations on Use

Suitable for residential use, taking into account the following:

  • For kitchen bins, if using a liner, take care to ensure the liner does not become entangled in the unit’s drawer runners.
  • Regularly remove crumbs, sticky residue or other matter from near and on runners using a soft brush or damp cloth.
  • Be familiar with the load capacity of the Tanova unit and do not exceed it.
  • When opening and closing the Tanova unit or when adding items to the bucket, do not apply strong downward force (such as pushing waste down with force to pack more into the bucket) as this may damage the runners.
  • Take care not to damage painted surface of the metal frames with hard or metallic objects. If the paint becomes chipped, it is recommended that the chip is repaired with a touch-up paint as recommended by a reputable paint supplier.
  • Do not use caustic cleaners on any part of the Tanova unit.
  • Some dishwasher powders are particularly caustic, as are dry salt, salt water and any citrus juice. If they spill onto the Tanova unit frame, remove the powder promptly with a soft brush or damp cloth taking care to re-wipe the surface clean after rinsing cloth free of substance.
  • Painted steel parts — clean with a soft brush or cloth, using warm water and a mild soap such as dishwashing liquid, which will help break down any stains. Avoid harsh chemicals.
  • Powder coated aluminium parts — clean with a soft brush or cloth, using warm water and a mild soap such as dishwashing liquid, which will help break down any stains. Avoid harsh chemicals. Wiping with a microfibre cloth is also a good dusting/cleaning method.
  • Plastic buckets — to avoid odours, regularly wash out with warm water and dishwashing liquid, rinse well and dry. If possible, leaving to dry in the sun is a great idea.
  • Plastic buckets are dishwasher safe.
  • Refer to the Care & Maintenance document for further detail.
In-Service History

FIT released their first Tanova Kitchen waste bin range in 2011, from which the current Simplex range has developed following a significant design review in 2014. ‘Frame and bucket’ options to sit on common soft close drawer brands followed in 2015, along with Simplex Plus. Options designed for compatibility with Legrabox drawers became available in 2019.

Other Performance Attributes
  • Simplex: 45kg
  • Simplex Plus: 30kg

Warranty

FIT warrants the original purchaser of products against manufacturing defects for as long as the original purchaser owns the product. This warranty applies to all non-electrical products sold by FIT in New Zealand and Australia.

The warranty covers replacements for faulty goods only. Replacements will be supplied to the original purchaser only. If the identical item is no longer available, FIT will replace with the closest item from their current product selection. The warranty does not include any labour or other associated expense that may be involved in removal or installation of the product. The warranty does not apply if products have been incorrectly installed, have been subjected to loads in excess of specifications and/or have been subjected to uses/purposes for which they are not expressly intended. FIT’s liability is limited to the goods themselves and does not cover any consequential or incidental damages contributed to or resulting from the use, installation, performance or failure of products.

In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).

Documents
Product Guides: Tanova Simplex Plus Kitchen Waste Bin Systems

2021

Assembly Instructions: Tanova Simplex Plus
Assembly Instructions: Tanova Simplex Plus — with 2x20L or 2x36L
Installation Instructions: Tanova Simplex
Installation Instructions: Tanova Simplex — 450mm Cabinets with 1x20L or 1x36L
Care & Maintenance: Tanova Kitchen Bins & Laundry Units

2024

FIT Warranty

2024

Tanova Out of Sight by Design Project Book

2026
