Equus Matacryl Carpark Waterproofing System
Description

The Equus Matacryl Traffic and Car Park System is a rapid finish trafficable waterproof membrane, for use in car parks, and pedestrian decks. The system provides a non-slip, low maintenance, waterproof and durable surface internally bonded to the substrate during application. The system is a liquid applied elastomeric waterproofing membrane designed to waterproof and protect concrete carpark decks. Designed for easy application and easy maintenance with an integrated non-skid surface profile for traffic, Mayacryl waterproofing also cures very quickly meaning minimal disruption and downtime for the building owner.



Key Features
  • Highly flexible membrane
  • Easy to apply using a roller or a squeegee
  • Thixotropic version available for vertical surfaces
  • Excellent waterproofing properties
  • Very high impact and puncture resistance
  • Withstands stress and movements in the substrate
  • Excellent adhesion to many types of substrate
  • Chemical and abrasion resistant
  • Can be applied over a wide range of ambient and substrate temperatures (-10°C to +35°C)
  • Easy repairs; excellent inter-layer adhesion due to chemical bonding
  • Overcoating time not critical
  • Fully cured one hour after application
Scope of Use

The Matacryl Carpark System is a multi-layer application, suitable for use over new or existing concrete. Matacryl membrane is commonly used for carparking applications, both interior and exterior, but can be used in a wide range of areas. Other applications can include as a bridge deck waterproofing, sub-grade waterproof detailing including below-grade slabs, pedestrian and vehicular trafficable areas, tunnels, channels and dam structures. The cured system is a very flexible crack-bridging membrane that retains its flexibility and crack-bridging performance in service even in low temperatures.

Statement of Building Code Compliance
  • B2 Durability - B2.3.1(c) In-service history shows Matacryl Waterproofing has a durability of at least 5 years when installed with the correct specification, installation and maintenance.
  • D1 Access routes - D1.3.3(d) Matacryl Waterproofing complies with D1/AS1 on level surfaces, and on sloping surfaces and stairs.
  • E2 External moisture - E2.3.1, E2.3.2, E2.3.7 Test data, together with in-service history in New Zealand and internationally, of the correctly installed Matacryl Waterproofing membrane over correctly designed and constructed substrates, show that the membrane successfully resists the ingress of moisture. See Tekton Consulting NZBC Compliance Report.
  • F2 Hazardous building materials - F2.3.1 Well known experience with the type of materials used together with in-service history, show that Matacryl Waterproofing complies with this performance requirement. Refer to SDS at www.equus.nz
  • Fire Resistance - Matacryl Waterproofing has been tested as per ISO 9239-1:2002 Reaction to fire tests for floorings. Radiant Flux = 6.6kW/m2

For more information see Tekton Consulting NZBC Compliance Report.

Documents
Product Statement: Equus Matacryl Carpark System

2024

Equus Document Library

Equus Industries Ltd provide technical waterproofing, tanking, coating and flooring solutions for architects, engineers, property managers and contractors in the building industry.
