Triton Duo 60 by Asona

Triton Duo 60

Asona

All products

Product Enquiries

Description

Triton Duo 60™ is a made in New Zealand mass loaded 60mm thick composite ceiling panel designed to provided attenuation of flanking and transmitted sound as well as broad band sound absorption for reverberation control. Triton panels are available in a wide range of sizes and decorative colours, wood prints, perforated acoustic patterns and Hygiene laminates for design freedom.

Manufactured in NZ from 50mm 48 kg/m³ bio-soluble glass fibre core with 10mm plasterboard attenuator backer, 320 gsm Sonatex™ / Sonaris™ acoustic laminate finishes.

Key Features

Very high sound absorption, NRC 0.95, ∂W 1.0, for effective reduction of background noise and reverberation times
High mass attenuator backer, STC 20 dB, CAC 44 to attenuate rain noise under metal roofs, plenum noise and room to room attenuation over partition heads
Ministry of Education DQLS V3.1 2024 compliant solution.
Fire group 1-S
Broad range of Sonatex and Sonaris perforated acoustic laminate finishes for design freedom
Service panels available to order with temporary foil overlay, designed to protect the decorative finish on site during installation, remove prior to hand over
Made in NZ, short lead times including replacement parts
Packaging take back & reuse scheme available
Product stewardship renew and reuse program
Green Tag Certified / Level A, low VOC, core contains 80% recycled post consumer waste glass
ISO 9001 registered quality management program
High light reflectance
Durable and dimensionally stable in high humidity
Custom sizes and finishes available
Optional Sonatex Hygiene laminate facing.

Ranges

Triton Sonaris Hygienic Decorative

NZ Made

NZ-Owned Business

Scope of Use

Triton Duo 60 is ideal for ceilings under metal roofs to control rain noise, mechanical services, buildings near aircraft flight paths, train lines or for private meeting room ceilings.

Suitable for fire exit way and all other sprinklered & non sprinklered buildings.

Limitations on Use

For interior use only, and not in direct contact with water.
Installation shall not commence until the building is watertight and dry
Light fittings shall be independently supported
Backloading max. 1.5 kg/m², point loads shall be independently supported
Max 99% R/H at 45°C
Use hold down clips in areas for seismic
Not for air return plenums

Statement of Building Code Compliance

NZ Building Act

This product is not subject to a warning or ban under Section 26.

NZ Building Code Compliance:

B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
C3 Fire – Clause C/AS2 4.12.1: Asona Triton Duo 60 has a Fire Material Group Number 1-S by NZBC Building Product Specification Parts 8.5.4 or 8.5.5, tested in accordance with ISO 9705 or ISO 5660.

In-Service History

Multiple uses, including schools.

Lane Neave
Auckland District Court
Competenz

Schools:

Mangere SC
Haeata Community College Theatre
Ormiston, Sunnyvale, Whaktipu

Other Performance Attributes

Light Reflectance — 85% per BS8493:2008, White
Very high sound absorption rating to control reverberation, NRC 0.95, ISO 11654 class A, αW 1.0.
Combined with good attenuation CAC 44, STC 20 to reduce the passage of noise.
Green Tag Certified level A, low VOC, core contains 80% recycled post consumer waste glass
Product stewardship renew and reuse program available
Packaging take back and reuse scheme available
Optional Sonatex Hygiene laminate facing.
