Triton 50 Bass™ is ideal to balance room acoustics in offices, educational facilities, music rooms, halls, studios.

Panels available with temporary protective foil covering to keep the panels clean during installation. Ideal for service panels.

• For interior use only, and not in direct contact with water.
• Not for use with negative air return plenums.
• Maximum humidity/temperature 99% R/H at 45°C.
• Back loading max. 1.5kg/m², point loads to be independently supported.

NZ Building Act

• This product is not subject to a warning or ban under Section 26.

NZ Building Code Compliance:

• B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
• C3 Fire – Clause C/AS2 4.12.1: Asona Triton 50 Bass has a Fire Material Group Number 1-S by NZBC Building Product Specification Parts 8.5.4 or 8.5.5, tested in accordance with ISO 9705 or ISO 5660.

Similar fabric covered variations have been used in:

• Radio NZ, Auckland
• ECU, Australia
• AMP Archive, Wellington
• Otago Uni Music School, Dunedin

• Light Reflectance Value: 85% per BS8493:2008, White
• Packaging Take Back Scheme: Flat pack cartons on site and return to Asona for reuse.
• Renew & Reuse Program: Soiled or damaged panels can be resurfaced on site or at the factory with new Sonatex or Sonaris laminates for reuse in the ceiling. Helps extend life cycle and reduce construction waste.
• Thermal Resistance: R 1.47 m²°C/W
• CAC 30 as standard.
• Fire Group 1-S.
• Global GreenTag certified Level A, low VOC, core contains 80% recycled post consumer waste glass.
• Optional Sonatex Hygiene laminate facing.
