InteriorInterior
Triton 15
Description

Triton 15™ is a made in NZ ISO class A high sound absorbing ceiling panel designed to control unwanted background noise and reverberation times. Triton 15™ is available in a wide range of acoustic laminate finishes, colours, prints and perforations.

Key Features
  • High sound absorption rating, NRC 0.90, ISO 11654 class A, αW 0.95 for effective control of noise reverberation.
  • Fire Group 1-S
  • Broad range of Sonatex™ and Sonaris™ decorative acoustic finishes for design flexibility.
  • Made in NZ, short lead times, including replacement panels.
  • Global GreenTag Certified Level A.
  • Product stewardship recycle and renew program available.
  • Low embodied energy, contains minimum 74% recycled glass waste.
  • Durable and dimensionally stable in high humidity.
  • Light weight, lower seismic design costs easy to work & trim.
  • Optional Sonatex Hygiene laminate facing.
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

Triton 15™ is ideal for use in open plan offices, libraries and other applications that require control of background noise.

  • Optional Sonatex Hygiene laminate facing.
Limitations on Use
  • For interior use only, and not in direct contact with water.
  • Not for use with negative air return plenums.
  • Maximum humidity/temperature 99% R/H at 45°C.
  • Back loading — No overlay loads, M&E services and point loads to be independently supported.
Statement of Building Code Compliance
  • B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
  • C3 Fire – Clause C/AS2 4.12.1: Asona Triton 15 has a Fire Material Group Number 1-S by NZBC Building Product Specification Parts 8.5.4 or 8.5.5, tested in accordance with ISO 9705 or ISO 5660.
In-Service History

Multiple interior installations.

Other Performance Attributes
  • From 74% recycled content, low embodied energy, product and packaging can be recycled in NZ.
  • VOC <0.002 Mg/M²/hr per ASTM D5116.
  • Global GreenTag Certified Level A.
  • Product stewardship recycle and renew program available.
  • Light Reflectance: 85% per BS8493:2008, White.
  • Optional Sonatex Hygiene laminate facing.
Green Tag Certified
Green Tag Certified
Documents
Asona Triton 15

26.08

Environmental Information - GreenTag Level A: Triton

260430
