Nuralite Provides Twice the Waterproofing, Without Twice the Price

There is a myth that double layer membrane waterproofing is significantly more expensive than single layer. The notion that twice the amount of material will cost twice the price is a way of thinking that Nuralite has been trying to change for years.

Nuralite's two layer 'bulletproof' system is the price equivalent of most other single layer alternatives currently provided in the market.

There are a number of reasons two-layer waterproofing can be just as cost-effective as a single layer. As a torch-on, Nuralite's Nuraply 3PM system has no need for expensive accessories such as the mechanical termination bars, gussets, sealants and adhesives required for single ply systems.

As well as the additional cost of these accessories, the increased time to install them is a another cost to factor in. Adhesive curing time itself can take up to seven days and prolong projects. These additions and steps are unavoidable in the single ply system and are required by manufacturers to gain a warranty. What's more, the homeowners will end up with a 7mm thick, double reinforced, 'bulletproof' system as opposed to a single layer around 1 — 1.5mm.

The addition of a Nuratherm Warmroof system would provide further long-term cost savings as it means increased energy efficiency and less heat loss through the roof. As with Nuraply 3PM, there is a 20-year warranty for the membrane system and there is also a lifetime warranty for the PIR board.

Specifying a Nuralite double layer membrane system with a Nuratherm Warm Roof system is more affordable than usually thought. It will provide a waterproof, warm home plus considerable cost and energy savings for many years to come.

Nuraply 3PM

Nuralite

View Product

Nuraply 3PM is used for waterproofing flat roofs or decks protected with timber or tiles.

Suitable for light maintenance foot traffic
Roof Solutions — suitable for installing over plywood, concrete or Nuratherm insulated roof substrates
Deck Solutions — waterproofing for decks, gutters, terraces and canopies

In the opinion of BRANZ , the Nuraply Roof and Deck Membranes, if designed, and used, installed and maintained in accordance with with the statements and conditions of Appraisal No.547 (2014), will meet the following provisions of the NZBC:

Clause B2 Durability: Performance B2.3.1(b), 15 years. Nuraply Roof and Deck Membranes meet these requirements.
Clause E2 External Moisture: Performance E2.3.1 and 2.3.2. Nuraply Roof and Deck Membranes meet these requirements.
Clause F2 Hazardous Building Materials: Performance F2.3.1. Nuraply Roof and Deck Membranes meet these requirements and will not present a hazard to people.

Nuraply Roof and Deck Membranes have been appraised as an Alternative Solution in terms of New Zealand Building Code compliance.

Durability

External Moisture

Hazardous Building Materials

BRANZ Appraised

CodeMark

Nuratherm Warm Roof System

Nuralite

View Product

The Nuratherm system puts the insulation where it should be, above the substrate, to completely enclose the roof area with a highly efficient insulation blanket.

The Nuraply Nuratherm System has been appraised by BRANZ for use as an insulating roof on buildings within the following scope:

the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1 with regards to building height and maximum floor plan areas; and,
on limited access flat roofs with concrete, timber or steel structural decks subject to specific structural design; and,
with roofs constructed to drain water to gutters and drainage outlets complying with the NZBC; and,
with roofs constructed to suitable falls (Refer Paragraph 15.3 and 15.4); and,
with no integral roof gardens; and,
situated in NZ3 3604 Wind Zones, up to, and including 'Extra High'.

The Nuraply Nuratherm System has also been appraised for durability and thermal performance as an insulated roofing system on buildings that are the subject of specific design with no building height restriction. Building designers are responsible for the building design and for the incorporation of the Nuraply Nuratherm System into their design in accordance with the declared properties and instructions of Nuralite Waterproofing Ltd.

Extra High Wind Zone

In the opinion of BRANZ , the Nuraply Nuratherm System, if designed, and used, installed and maintained in accordance with with the statements and conditions of Appraisal No.732 (2012), will meet the following provisions of the NZBC:

Clause B2 Durability: Performance B2.3.1(b), 15 years. Nuraply Nuratherm System meet this requirement
Clause E2 External Moisture: Performance E2.3.1 and 2.3.2. Nuraply Nuratherm System meet these requirements
Clause F2 Hazardous Building Materials: Performance F2.3.1. Nuraply Nuratherm System meet this requirement and will not present a hazard to people
Clause H1 Energy Efficiency: Performance H1.3.1(a). The Nuraply Nuratherm System will contribute to meeting this requirement

Nuraply Nuratherm System is appraised as an Alternative Solution in terms of New Zealand Building Code compliance.

Durability

External Moisture

Hazardous Building Materials

Energy Efficiency

BRANZ Appraised
