• ASPEN can be used in areas with a maximum wind pressure of 1.76kPa (Very High Wind Zone) and a Maximum Snow Load of 1kPa.

ASPEN is designed to be fixed to:

• Steel structures
• Structural timber facades
• Concrete facades

Heavyweight ASPEN canopy is designed to take:

• 15mm Viridian toughened safety glass
  or
• 17.5mm Viridian toughened SENTRYGLAS laminated safety glass

• Solid and Rigid framework needs to be taken into consideration with designing an ASPEN canopy system
• The tie rods and wall mounts need to fixed into a solid structure that is designed to take the relevant loads
• A structural engineer will need to ensure the structure to which the ASPEN system is fixed to is suitable
• SENTRYGLAS must be used if the ASPEN system is 5m or greater from the finished floor level

A structural engineer will need to ensure the structure to which the ASPEN system is fixed to is suitable.

• PS1 is available upon request

This proprietary canopy system complies with New Zealand Building Code Clauses:

• B1 Structure
• B2 Durability
• E2 External Moisture (specific design is required)
• F2 Hazardous Building Materials

SENTRYGLAS is a toughened laminated glass that has a rigid interlayer. The SENTRYGLAS interlayer provides added safety, in the unlikely event of both the toughened glass panes breaking; the SENTRYGLAS interlayer will hold the toughened glass fragments together stopping them from falling to the floor or over people that may be under the glass.
