FrogLink — Surface Mounted Roof Anchor
Description

The SafetyLink FrogLink is a surface-mounted single-person roof anchor designed for fall arrest applications on metal roof systems.

Manufactured from 316 stainless steel, it attaches directly to a wide range of metal roof profiles using a single row of fixings without requiring access to the roof structure below.

The system is intended for permanent installation on commercial, industrial and residential buildings requiring compliant roof access and fall protection.

Key Features
  • Surface-mounted roof anchor for metal roof systems.
  • Manufactured from 316 stainless steel.
  • Single-person fall arrest anchor rated to 15 kN.
  • Multi-directional loading capability (360° fall arrest).
  • Compatible with corrugated, Trimdek®, Klip-Lok® and similar metal roof profiles.
  • Single row fixing pattern simplifies installation.
  • Low-profile design with minimal visual impact.
  • Dynamic energy-absorbing design reduces loads transferred to the user and supporting structure.
  • Installed using approved SafetyLink components and fixings.
Scope of Use
  • Permanent roof fall protection systems.
  • Commercial, industrial and residential buildings.
  • Metal roof cladding including corrugated, Trimdek®, Klip-Lok® and compatible profiles as will as Ply roof strctures.
  • Maintenance access to roofs containing plant, equipment, gutters and services.
  • New construction and retrofit applications.
  • Integration into engineered fall arrest systems designed in accordance with AS/NZS 1891.
Limitations on Use
  • Suitable for compatible ply and metal roof systems only.
  • System supplied, installed and certified by Total Height Safety in accordance with the manufacturer's requirements.
  • Not intended as a horizontal lifeline support.
  • Not designed for rope access unless specifically engineered.



Statement of Building Code Compliance

Contributes towards compliance with NZBC:

  • B1 Structure
  • B2 Durability
  • F4 Safety from Falling

Tested and manufactured in accordance with AS/NZS 1891.2 and other referenced international standards.

Other Performance Attributes
  • 316 stainless steel components.

Warranty & Maintenance

  • Manufacturer's warranty applies when installed in accordance with SafetyLink requirements.
  • Inspect and re-certify by a competent person in accordance with AS/NZS 1891.4.
Documents
Height Safety Systems and Design Guide
Data Sheet: FrogLink
7938TH Product Specification
DESIGN: No Substitution Principle
Specification Guide
Total Height Safety on Masterspec
Flyer: FrogLink
