The thickness of the VP240-S door leaf is 83mm with Plywood facings or 77mm with Steel facings. The approximate leaf weight is at least 41kg/m2.

Wall Types

The VP240-S slider may be hung from a concrete or masonry wall either of precast concrete (thickness 150mm minimum) or grouted blockwork (thickness 190mm minimum).

Installation on plasterboard walls no longer compliant as of February 2024.

• Thermal insulation

  This door leaf has a thermal insulation rating (R-value) of 0.692 Km2/W.

• Hardware/Closing Systems



  A Standard Track System is supplied with this door set.

  Standard Closer

  Weight and pulley system with self-closure activated by fusible link in the event of fire.

  Electromagnetic Closing Weight System

  A weight and pulley system modified for electromagnetic release is available. Closure is on fire/smoke detection activated by sensors (by others) mounted each side of the door set to lintel or ceiling.
