XTREME 70/33 II Glass is suitable for commercial, institutional, multi-residential and retail.

Suitable for:

• Premium commercial façades
• Curtain walls
• Structural glazing systems
• Offices, healthcare and education buildings
• Large glazed areas
• Skylights and atriums
• High end residential glazing

• Must be thermally processed before unit manufacture
• Coating must be edge deleted
• Normally positioned on surface two
• Appearance should be approved using a project sample
• Glass make up must suit the project loads and safety requirements
• Performance depends on the complete insulated glass and framing system
• Must be installed in accordance with Metro requirements and NZS 4223

When correctly specified, manufactured and installed as part of a compliant window or façade system, XTREME 70/30 II can contribute to compliance with:

• B1 Structure
• B2 Durability
• E2 External Moisture
• F2 Hazardous Building Materials
• G7 Natural Light
• H1 Energy Efficiency

Compliance must be assessed for the complete glazing and framing system.

• Ug centre of glass: 1.1
• Visible light transmission: 70%
• External light reflectance: 11%
• Internal light reflectance: 13%
• Solar factor or g value: 33 %
• Fading protection Tdw ISO: 0.52
• Appearance: Highly neutral

XTREME 70/33 II provides the highest natural light transmission in the XTREME range, combined with strong solar control and low reflectance.

Warranty & Maintenance

• Qualifying Metro insulated glass units are covered by the applicable Metro warranty
• Refer to the attached Metro warranty document and registration requirements
• Maintain in accordance with the Metro glass care and maintenance guide
• Maintain framing, seals, drainage paths and building interfaces
