XTREME 61/29 II Glass is suitable for commercial, institutional, multi-residential and retail.

Suitable for:

• Commercial curtain walls
• Structural glazing
• Office buildings
• Healthcare and education projects
• Large glazed façades
• Highly sun exposed elevations
• Renovation and new build projects
• Selected overhead glazing

• Must be thermally processed before unit manufacture
• Coating must be edge deleted
• Normally positioned on surface two
• Appearance should be approved using a project sample
• Glass make up must suit the project loads and safety requirements
• Performance depends on the complete insulated glass and framing system
• Must be installed in accordance with Metro requirements and NZS 4223

When correctly specified, manufactured and installed as part of a compliant window or façade system, XTREME 61/29 II can contribute to compliance with:

• B1 Structure
• B2 Durability
• E2 External Moisture
• F2 Hazardous Building Materials
• G7 Natural Light
• H1 Energy Efficiency

Compliance must be assessed for the complete glazing and framing system.

Performance data is based on a nominal 4 14 4 double glazed unit with argon gas and a thermal spacer:

• Ug centre of glass: 1.1
• Visible light transmission: 61 %
• External light reflectance: 11 %
• Internal light reflectance: 15 %
• Solar factor or g value: 29%
• Fading protection Tdw ISO: 0.50
• Appearance: Neutral with low reflectance

XTREME 61/29 II provides strong solar control while maintaining good natural light, high selectivity and a neutral façade appearance.

Warranty & Maintenance

• Qualifying Metro insulated glass units are covered by the applicable Metro warranty
• Refer to the Metro warranty document and registration requirements
• Maintain in accordance with the Metro glass care and maintenance guide
• Maintain framing, seals, drainage paths and building interfaces
