SKN 152 II Glass is suitable for commercial, institutional, multi-residential and retail.

Suitable for:

• North, east and west facing façades
• Large commercial curtain walls
• Offices and institutional buildings
• Highly sun exposed glazing
• Shopfronts and entrances
• Large windows and glazed walls
• Selected overhead glazing

• Lower daylight transmission than SKN 176 II and SKN 165 II
• Must be thermally processed before unit manufacture
• Coating must be edge deleted
• Normally positioned on surface two
• Appearance and daylight levels should be reviewed during design
• Performance depends on the complete unit and framing system
• Must be installed in accordance with Metro requirements and NZS 4223

When correctly specified, manufactured and installed as part of a compliant window or façade system, SKN 152 II can contribute to compliance with:

• B1 Structure
• B2 Durability
• E2 External Moisture
• F2 Hazardous Building Materials
• G7 Natural Light
• H1 Energy Efficiency

Compliance must be assessed for the complete glazing and framing system.

Performance data is based on a nominal 4 14 4 double glazed unit with argon gas and a thermal spacer:

• Ug centre of glass: 1.1
• Visible light transmission: 50%
• External light reflectance: 18%
• Internal light reflectance: 14%
• Solar factor or g value: 26%
• Fading protection Tdw ISO: 0.38
• Appearance: Neutral

SKN 152 II provides stronger solar control than SKN 176 II and SKN 165 II while maintaining moderate natural light and a neutral architectural appearance.

Warranty & Maintenance

• Qualifying Metro insulated glass units are covered by the applicable Metro warranty
• Refer to the attached Metro warranty document and registration requirements
• Maintain in accordance with the Metro glass care and maintenance guide
• Maintain framing, seals, drainage paths and building interfaces
