FSR – Austvision Folding Stacking Rail Door

Austvision frameless folding door systems are designed for heavy duty commercial applications up to 3.0m maximum opening height.

The Austvision frameless door systems are available in two variants:

  • Austvision Slydstack door system
  • Austvision Bi-Folding door system.

The key difference between the two systems is the way the door leaves are stored. The Slydstack door system stacks individual door leaves parallel to one another in a left or right handed stacking bay, while the Bi-Folding door system pairs and folds the individual door leaves along the overhead track.

The glass is suspended from the overhead aluminium track using door rails or door spider fittings. A maximum of 15mm toughened, heat soaked tested glass can be supported in the door rail option or a maximum of 12mm in the door spider fitting option.

Austvision frameless door systems feature innovative dual nylon wheels in the roller carriages for better weight distribution and stability. All Austvision frameless door systems come standard with Euro type plunger locks, floor weather seals and head smoke seals.

Finishes available in:

  • Satin stainless steel finish
  • Polished stainless steel finish
  • Mill aluminium covers for powder coating/ anodising on request only.
