• For exterior use of stone and pavers >25mm
• Can be used to install paving elements with an even or irregular thickness and particularly thick and/or trapezoidal shaped elements on compact installation beds
• Suitable for surfaces with vehicle access
• Suitable for exposure classes XF4 and XS3, Mapestone has high compressive strength and resistance to freeze-thaw cycles, de-icing salts and seawater
• Substrates must be structurally sound, dry, solid and stable
• The bonding slurry is created by mixing water, cement and PLANICRETE which improves adhesion, compressive and flexural strengths, abrasion, impermeability and environmental resistance
• Grout for architectural flagstone and block paving is available in neutral and dark grey (MAPESTONE PFS 2 VISCO)
• Complete the system with a neutral mould resistant sealant (MAPESIL LM)
• Mapestone systems have been used in projects across the world with varying climates from Italy and Spain, to Hong Kong and Norway
• Find the full installation information and procedure in the documents section.

• Protect the flooring for at least 12 hours after application.

RELEVANT DOCUMENTATION

A. Australian Standard(s):

1. AS-3985:2023 - Installation of Ceramic and Stone Tiles

• EPD certified products include: MAPESTONE TFB 60, MAPESTONE PFS 2 VISCO, PLANICRETE
• VOC emission tested products include: MAPESIL LM
• Mapestone interventions are highly durable to freezing weather, de-icing salts, seawater and the abrasive action of road-sweepers
• More than 1,000 buses drive over a Mapestone system road every day
• Areas where the system has been installed can be reopened to traffic very quickly
• For EN 206 exposure classes XF4 and XS3
